Test Compass
Positions Antenna to a level Elevation angle and updates compass
heading.
Test Elevation
Moves dish to the values set in the Start Angle and End/Demo Angle
fields
Test Azimuth
Moves dish to the values set in the Start Angle and End/Demo Angle
fields
Test Polarization
Rotates dish to the values set in the Start Angle and End/Demo Angle
fields
Test EL/AZ/PL
Moves and rotates to the values set in the Start Angle and End/Demo
Angle fields
Stop Demo/Test
Halts all test/demo sequences
Modem Test
The user may enter certain modem commands, and click send. The 7000 will then read
the response from the modem in the text area below the command line. Currently the
commands supported are for iDirect service:
 laninfo

tx power

tx freq

tx symrate

tx cw

rx power

rx freq

rx symrate
