Instruction manual Gas Cooker BGC60TW BGC60TB
You’ll soon be enjoying your new Gas Cooker. It all begins here, with your instructions. Don’t worry, there’s nothing too technical coming up. Just simple, step-by-step guidance to get you up and running quickly. Sound good? Then let’s get started. Help and Guidance We’re here to help you get the most from your Combined Gas Cooker. Should you require any guidance, a simple solution can often be found online at: www.argos-support.co.
Contents 1 Safety information 2 6 Safety information 6 7 Getting to know your Gas Cooker Ready? Let’s begin 10 Product features Control panel 3 4 5 11 Installing your Gas Cooker Installatıon and preparatıon for use 16 Gas connection 17 Gas conversion (If available) 19 Electrical connection and safety 21 Anti-tilting kit 21 Adjusting the feet 22 Care and Maintenance Cleaning 38 Maintenance 39 Product support Troubleshooting 42 Transport 42 Help and assistance 43 Declaratio
Safety information 1
Safety information Important - Please read these instructions fully before installing or operating • • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. This manual has been prepared for more than one model therefore your appliance may not have some of the features described within. For this reason, it is important to pay particular attention to any figures whilst reading the operating manual.
Safety information Important - Please read these instructions fully before installing or operating should be installed and connected in accordance with current installation regulations. Particular attention shall be given to the relevant requirements regarding ventilation. • • If the burner has not lit after 15 seconds, stop operating the device and open the compartment door. Wait at least 1 minute before attempting to ignite the burner again.
Safety information Important - Please read these instructions fully before installing or operating • The trays incline when pulled out. Take care not to spill or drop hot food when removing it from the oven. CAUTION: The use of a gas cooking appliance results in the production of heat, moisture and products of combustion in the room in which it is installed.
Safety information Important - Please read these instructions fully before installing or operating or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Getting to know your gas cooker 2
Getting to know your gas cooker You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your Electrical Cooker and ensure safe and correct installation and operation. If you require any further assistance, our technical experts are happy to help. For full details, refer to the product support section at the end of these instructions.
Getting to know your gas cooker You’ll be up and running in no time List of Components Product features Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. 1 2 3 Accessorries 4 The Grill Pan and Handle Set 5 6 The Wire Grid 7 The Coffee Adaptor 1. Cooktop 2. Control Panel 3. Top Oven Door Handle 4. Top Oven Door 5. Main Oven Door Handle 6. Main Oven Door 7. Adjustable Feet Control panel 11 11 8.
Installing your gas cooker 3
Installing your gas cooker Bringing it all together Installatıon and preparatıon for use WARNING : This appliance must be installed by an authorised service person or qualified technician, according to the instructions in this guide and in compliance with the current local regulations. Incorrect installation may cause harm and damage, for which the manufacturer accepts no responsibility and the warranty will not be valid.
Installing your gas cooker Bringing it all together combustible materials in the close vicinity, such as curtains, oil, cloth etc. which may catch fire. • The worktop and furniture surrounding the appliance must be made of materials resistant to temperatures above 100°C. • The appliance should not be installed next to a dishwasher, fridge, freezer, washing machine or clothes dryer.
Installing your gas cooker Bringing it all together ensure the minimum gas consumption. If the pressure of used gas is different than the values stated or is not stable in your area, it may be necessary to assemble an available pressure regulator on the gas inlet. You should contact an authorised service centre to make these adjustments.
Installing your gas cooker Bringing it all together Gas pipe Burner cap Adapter Seal Mechanical gas hose Cup Mechaniccal gas hose Spanner Adapter Mechanical gas hose The Cooker must be installed and maintained by a suitably qualified gas registered technician in accordance with current safety legislation. WARNING: Do not use a naked flame to check for gas leaks. Gas conversion Grill injector The grill injector is held in position by a single screw on the tip of the burner.
Installing your gas cooker Bringing it all together the left and, with your other hand, lift the burner up holding from the thermocouple/spark plug holder. The injector is on the right-hand side of the burner cradle. Repeat the same procedure for both the Main and Top Oven (if present) burners.
Installing your gas cooker Bringing it all together for NG/LPG gases. In this case, remove the current connection components and nuts (if any) and connect the new gas supply accordingly. In all conditions, all components used in gas connections should be approved by local and/or international authorities. In all gas connections, refer to the “Assembly of gas supply and leakage check” clause explained above.
Installing your gas cooker Bringing it all together Adjusting the feet A Your product stands on four adjustable feet. For safe operation, it is important that your appliance is correctly balanced. Make sure the appliance is level prior to cooking. To increase the height of the appliance, turn the feet anti-clockwise. To decrease the height of the appliance, turn the feet clockwise. Wall Antitilting bracket It is possible to raise the height of the appliance up to 30 mm by adjusting the feet.
Installing your gas cooker Bringing it all together or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Functions 4
Functions Simple everyday use Use of gas burners Ignition of the burners The position symbol above each control knob indicates the burner that the knob controls. Manual ignition of the gas burners If your appliance is not equipped with an ignition aid, or in case there is a failure in the electric network, follow the procedures listed below. For hob burners: Push in the knob of the burner you wish to ignite and keep it pressed while turning it anticlockwise until the knob is in the ‘maximum’ position.
Functions Simple everyday use no liquid in the burner caps. If the burner flames go out accidentally, switch the burners off, ventilate the kitchen with fresh air and wait at least 90 seconds before attempting re-ignition. • The temperature of accessible parts may become high while the appliance is operating. It is imperative that children and animals are kept well away from the burners during and after cooking. • After use, the hob remains very hot for a prolonged period of time.
Functions Simple everyday use clockwise direction. Always use the oven between the maximum and minimum settings. When switching the oven off, turn the knob in the clockwise direction to the “0” position. Preheating We recommend you preheat the oven for 10 minutes before use. For recipes needing high temperatures, such as bread, pastries, scones or soufflés, best results are achieved if the oven is preheated first.
Functions Simple everyday use Assembling the grill heat shield during cooking. Food should be placed in the centre of the grid to allow for maximum circulation of air. Never cover the grill pan or grid with foil as this can lead to grill fires. If your appliance has a grill pan and handle set as an accessory, refer to the accessories section for information on using it. WARNING: Make sure that the grill is switched off before closing the oven door. Hold the heat shield with the warnings facing upwards.
Using your gas cooker 5
Using your gas cooker Getting the most from your appliance Accessorries The wire grid The coffee adaptor The wire grid is best used for grilling or for processing food in oven-friendly containers. Place the coffee adaptor on the auxiliary burner grid to prevent the cookware from tipping over when the small burner is in use. WARNING The wire grid is used for grilling or for processing food in other containers.
Using your gas cooker Getting the most from your appliance Injector table G30 28-30mbar 12.0 kW 873 g/h II2H3+ GB Class: 1 NG G20 20 mbar LPG G30/G31 28-30/37 mbar DIA. of INJECTOR (1/100mm) 115 85 NOMINAL RATING (kW) 2,9 3 276 l/h 218,1 g/h 97 65 LARGE BURNER CONSUMPTION MEDIUM BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (kW) CONSUMPTION 1,75 1,75 166.7 l/h 127,2 g/h MEDIUM BURNER DIA. of INJECTOR (1/100mm) 97 65 1,75 1,75 166.7 l/h 127,2 g/h 72 50 1 1 95.
Using your gas cooker Getting the most from your appliance Energy fiche Brand BGC60TW BGC60TB Model Type of Oven GAS Mass kg Energy Efficiency Index - conventional 38,4 (+/-2) 105,3 Energy Efficiency Index - fan forced - Energy Class A Energy consumption (gas) - conventional MJ/cycle - kWh/cycle 5,94 1,65 Energy consumption (gas) - fan forced MJ/cycle - kWh/cycle - Number of cavities 1 Heat Source GAS Volume l 48 This oven complies with EN 15181 Energy Saving Tips Oven - Cook the m
Using your gas cooker Getting the most from your appliance Brand BGC60TW BGC60TB Model Type of Hob Gas Number of Cooking Zones 4 Heating Technology-1 Gas Size-1 Energy Efficiency-1 Auxiliary % Heating Technology-2 Size-2 Energy Efficiency-2 Semi-Rapid % Heating Technology-3 59,0 Gas Size-3 Energy Efficiency-3 NA Gas Semi-Rapid % Heating Technology-4 59,0 Gas Size-4 Rapid Energy Efficiency-4 % 57,0 Energy Efficiency of Hob % 58,3 This hob complies with EN 30-2-1 Energy Saving Tips
Care and maintenance 6
Care and maintenance Looking after your appliance hob burners. Cleaning WARNING: Switch off the appliance and allow it to cool before cleaning is to be carried out. General instructions • • Check whether the cleaning materials are appropriate and recommended by the manufacturer before use on your appliance. Use cream cleaners or liquid cleaners which do not contain particles.
Care and maintenance Looking after your appliance Do not clean the stainless steel parts while they are still hot from cooking. Do not leave vinegar, coffee, milk, salt, water, lemon or tomato juice on the stainless steel for a long time. Removal of the oven door Before cleaning the oven door glass, you must remove the oven door, as shown below. 1. Open the oven door. Maintenance WARNING: The maintenance of this appliance should be carried out by an authorised service person or qualified technician only.
Product support 7
Product support Help is always at hand Troubleshooting If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Oven and/or grill (if available) do not work. The oven and/or grill may be in the ´off` position. Supply gas pressure may not be correct. Power (if the appliance has an electric connection) is switched off. The feet have not been assembled.
Product support Help is always at hand Help and assistance If you require any technical guidance or find that your is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271*.
Product support Help is always at hand Declaration of conformance to product standards Disposal • We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. We apologise for any inconvenience caused by any minor inconsistencies in these instructions , which may occur as a result of product improvemenst and development.
Product support Help is always at hand Call us now and activate your 12 month guarantee Thank you for choosing Bush. Your new product is guaranteed against faults and breakdowns for 12 months. Don’t forget to register it with us today so we can provide you with our best possible after-sales service and useful updates. www.bushregistration.co.uk FREEPHONE* 0800 597 8548 Lines are open 8am - 8pm, 365 days a year. *Calls may be recorded and monitored.
