Operating Instructions

251
Front-seat height
with rider's seat, low
OE
with rider's seat, high
OE
Rider's inside-leg arc, heel to
heel
with rider's seat, low
OE
with rider's seat, high
OE
31.7...32.5 in (805...825 mm),
without rider, at DIN unloaded
vehicle weight
29.9...30.7 in (760...780 mm),
without rider, at DIN unloaded
vehicle weight
32.7...33.5 in (830...850 mm),
without rider, at DIN unloaded
vehicle weight
71.3...72.8 in (1810...1850 mm),
without rider, at DIN unloaded
vehicle weight
68.5...70.1 in (1740...1780 mm),
without rider, at DIN unloaded
vehicle weight
73.8...75.4 in (1875...1915 mm),
without rider, at DIN unloaded
vehicle weight
WEIGHTS
Unloaded vehicle weight 615 lbs (279 kg), DIN un-
loaded vehicle weight, ready
for road, 90% full tank of gas,
without OE
Gross vehicle weight 1113 lbs (505 kg)
Maximum payload 498 lbs (226 kg)
Payload per case max 22 lbs (max 10 kg)
Payload of Topcase max 11 lbs (max 5 kg)
