220 MAINTENANCE
Press the hook 1 and remove
the diagnostic socket 2 by
pulling it upwards.
Press locks 3 on both sides.
Loosen the diagnostic
socket 2 from the bracket 4.
The interface for the diagno-
sis and information system
can be connected to the diag-
nostic socket 2.
Fastening the diagnostic
socket
Disconnect the interface for
the diagnosis and information
system.
Plug the diagnostic socket 2
into the bracket 4.
The locking mechanisms 3
engage on both sides.
Connect the bracket 4 to the
mount 1.
Make sure that the hook 5
engages.
Installing battery cover
( 217).
