Operating Instructions

211
Fastening silencer
ATTENTION
Tightening of screwed
connections with incorrect
tightening torque
Damage or loosening of
screwed connections
Always have the tightening
torques checked by a
specialized workshop,
preferably an authorized
BMW Motorrad retailer.
Turn silencer 1 anti-clockwise
until it rests on the passenger
footpeg bracket.
Install lock washer 2 and
screw 3.
Muffler on rear frame
14 lb/ft (19 Nm)
Shift the circlip with recess 1
as far forward as possible and
align it with the snap-in lug 2.
Snap-in lug engages in the
recess of the circlip.
Tighten circlip 1.
Clamp on muffler and
exhaust manifold
16 lb/ft (22 Nm)
Position muffler cover 3.
Install screws 1.
Install the screw with lock
washer 2.
Trim on end muffler
4 lb/ft (5 Nm)
