Manual

28
GB
MULTIPOLE MODULE
8
27
13
22
23
24
25
8 FE contact
27 Labelling fi elds
13 Type plate
22 Labelling fi eld
Input M23
23 Connection
Inputs M23
24 Labelling fi eld
Outputs M23
25 Connection
Outputs M23
29
GB
PIN connection
PIN Assignment
M23
Inputs
jacks
1 ... 5 IN
1
... IN
5
6 GND_Inputs
7 ... 11 IN
6
... IN
10
12 24V_Inputs
13 ... 18 IN
11
... IN
16
19 GND_Inputs
PIN Assignment
M23
Outputs
jacks
1 ... 5 OUT
1
... OUT
5
6 GND_Outputs
7 ... 11 OUT
6
... OUT
10
12 GND_Outputs
13 ... 18 OUT
11
... OUT
16
19 GND_Outputs
30
GB
INTERMEDIATE MODULE
(INSIDE MODULE)
Technical data
Operating voltage 24 V; -15 % / +20 %
Residual ripple 2 V
ss
Current consumption
Inputs / Logic max. 1 A
Outputs max. 4 A (M12)
Overview
Detail drawing Diagnostic / Status LEDs (20)
I
I
S
S
O
O
U
U
U
U
U
U
RIO
RIO
Power
RIO Status U
i
Logic voltage
U
S
Sensor
voltage
U
O
Output vol-
tage
31
GB
I
I
S
S
O
O
U
U
U
U
U
U
RIO
RIO
Power
Power
9
23
22
21
20
8
8 FE contact
9 FE contact
20 Diagnostic/status
LEDs (see detail
drawing)
21 DIN rail mounting
22 Label panel
Power
23 Connection
Power M12
PIN connection
PIN M12, 4-pin
1 +24 V
Output (U
0
)
2 +24 V
Logic /Sensors (U
i
)
3 GND
Logic /Sensors (U
i
)
4 GND
Output (U
O
)
