User's Manual

LPA2100-160-SW01
BRAVO TECH INC
Add.: 6185 Phyllis Drive Unit D, Cypress, CA 90630
Phone: [phone] Website: www.bravotechinc.com
Revision: SP·LPA2100-160-SW01·REV.A
Page: 7
7. Assembled
Figure 4 Assembled Instructions
1. Lock 5 screws 4-40, L3/8 inch with Philip's type screwdriver to fasten the front side of PA to
the Front Plate of Booster as shown above.
2. Lock 3 screws 4-40, L5/8 inch with Philip's type screwdriver to fasten the back side of PA to a
connection board which is connected to the soleplate of Booster.
5 screws 4-40, L3/8 inch
3 screws 4-40, L5/8 inch
