User's Manual Part 1

section 06
page
19
40040005 rev. 000
Step 2. Lower the chair all the way down to its lowest position.
Step 3. Using the latch on the right side, open the halo (Figure 6-34).
Step 4. Ask the patient to sit in the chair.
Step 5. Adjust the height of the seat, the position of the seat, the position of the back
of the chair, the height of the back of the chair, and the arm rests to accommodate the
patient’s size, height, and posture. Set the halo height to 3 as a starting position (Figure
6-35).
Step 6. Secure the patient with the waist strap and shoulder straps (Figure 6-36).
Step 7. Close and lock the halo (Figure 6-37).
Figure 6-36. Waist and Shoulder Straps
Figure 6-33 Insert
ROM Stop
Figure 6-34. Open Halo
Figure 6-35. Seat Adjustments
