System information

24
ONLY DIPSWITCH
1 ON
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
LOWER * MIDDLE UPPER
55 191 196 197
60 205 210 212
65 221 226 227
70 237 243 244
75 255 261 263
80 274 281 283
85 295 302 305
90 316 325 328
95 339 349 352
100 364 374 378
105 390 401 406
110 417 430 435
115 445 460 465
120 475 491 497
125 505 524 530
PRINTED FROM D155861P01 REV 2
* Data is based on 10.1° of subcooling at a 95° ambient
Liquid
Tem
p
(
°F
)
2 TON AC R410A REFRIGERANT CHARGING CHART
LIQUID GAGE PRESSURE (PSIG)
ONLY DIPSWITCH
1 ON **
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
LOWER * MIDDLE UPPER
55 186 186 190
60 202 202 206
65 219 219 222
70 237 237 240
75 256 256 260
80 277 277 280
85 299 299 302
90 322 322 325
95 346 346 350
100 371 371 375
105 397 397 402
110 425 425 430
115 454 454 460
120 484 484 491
125 515 515 523
** With AM7 or AM8: Dip switch 1 = 11° of subcooling at 95° ambient
PRINTED FROM D155861P02 REV 2
3 TON AC R410A REFRIGERANT CHARGING CHART
* Data is based on 10.5° of subcooling at a 95° ambient
Liquid
Temp (°F)
LIQUID GAGE PRESSURE (PSIG)
ONLY DIPSWITCH
1 ON **
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
LOWER * MIDDLE UPPER
55 200 203 208
60 217 221 225
65 235 239 243
70 254 258 263
75 274 279 284
80 295 301 306
85 318 323 329
90 341 347 354
95 366 372 379
100 392 398 406
105 418 426 434
110 446 454 464
115 475 483 495
120 506 514 526
125 537 545 560
PRINTED FROM D155861P03 REV 2
* Data is based on 15.0° of subcooling at a 95° ambient
** With AM7 or AM8: Dip Switch 1 = 13° subcooling at a 95° ambient
4 TON AC R410A REFRIGERANT CHARGING CHART
Liquid
Tem
p
(
°F
)
LIQUID GAGE PRESSURE (PSIG)
ONLY DIPSWITCH
1 ON
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
LOWER * MIDDLE UPPER
55 191 197 201
60 207 213 218
65 224 231 236
70 242 249 255
75 261 268 275
80 281 289 296
85 302 310 318
90 324 333 342
95 347 356 366
100 372 381 392
105 397 407 418
110 423 434 446
115 451 462 474
120 479 491 504
125 509 521 535
PRINTED FROM D155861P04 REV 2
5 TON AC R410A REFRIGERANT CHARGING CHART
Liquid
Tem
p
(
°F
)
LIQUID GAGE PRESSURE (PSIG)
* Data is based on 11.2° of subcooling at a 95° ambient
ONLY DIPSWITCH
1 ON
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
SEE TABLE A * SEE TABLE A SEE TABLE B
55 192 199 210
60 206 213 227
65 221 229 245
70 238 246 264
75 256 264 284
80 275 284 306
85 295 305 329
90 316 327 354
95 339 350 380
100 363 374 407
105 388 400 435
110 415 427 465
115 443 456 497
120 471 485 529
125 502 516 563
PRINTED FROM D155859P01 REV 4
** Data is based on 18.0° of subcooling at a 95° ambient
2 TON HP R410A REFRIGERANT CHARGING CHART
Liquid
Temp (°F)
LIQUID GAGE PRESSURE (PSIG)
* Data is based on 9.5° of subcooling at a 95° ambient
ONLY DIPSWITCH
1 ON **
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
LOWER * MIDDLE UPPER
55 194 195 199
60 208 210 215
65 224 227 232
70 242 246 250
75 260 265 270
80 280 286 291
85 301 308 313
90 324 331 337
95 348 356 362
100 373 382 388
105 399 409 416
110 427 438 445
115 456 467 475
120 486 498 507
125 517 531 540
** With AM7 or AM8: Dip switch 1 = 10° of subcooling at 95° ambient
PRINTED FROM D155859P02 REV 4
3 TON HP R410A REFRIGERANT CHARGING CHART
* Data is based on 11.5° of subcooling at a 95° ambient
LIQUID GAGE PRESSURE (PSIG)
Liquid
Temp (°F)
ONLY DIPSWITCH
1 ON
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
SEE TABLE B ** SEE TABLE A * SEE TABLE A
55 202 204 206
60 217 220 223
65 234 238 240
70 251 256 259
75 270 277 280
80 290 298 301
85 312 321 325
90 334 345 349
95 358 370 375
100 383 397 403
105 409 425 432
110 436 454 462
115 465 485 494
120 494 516 527
125 525 550 562
** With AM7 or AM8: Dip switch 1 = 13° of subcooling at 95° ambient
PRINTED FROM D155859P03 REV 4
** Data is based on 13.5° of subcooling at a 95° ambient
LIQUID GAGE PRESSURE (PSIG)
Liquid
Temp (°F)
4 TON HP R410A REFRIGERANT CHARGING CHART
* Data is based on 15.9° of subcooling at a 95° ambient
ONLY DIPSWITCH
1 ON
ONLY DIPSWITCH
2 ON
ONLY DIPSWITCH
3 ON
LOWER * MIDDLE
UPPER & 4TEE3_10
DOWNFLOW & HORIZ.
LEFT **
55 208 208 210
60 225 225 227
65 242 242 245
70 260 260 264
75 280 280 284
80 300 300 305
85 322 322 327
90 345 345 350
95 369 369 374
100 394 394 400
105 420 420 426
110 447 447 454
115 476 476 483
120 505 505 513
125 536 536 544
PRINTED FROM D155859P04 REV 4
** Data is based on 16.7° of subcooling at a 95° ambient
* Data is based on 14.8° of subcooling at a 95° ambient
LIQUID GAGE PRESSURE (PSIG)
Liquid
Tem
p
(
°F
)
5 TON HP R410A REFRIGERANT CHARGING CHART
2 Ton AC
Note: See page 20 for subcool charging correction tables A and B
3 Ton AC
4 Ton AC
5 Ton AC 5 Ton HP
4 Ton HP
3 Ton HP
2 Ton HP
