- Start Here
24
Windows
®
Wired Network
c Carefully route the network cable through the
trench and out the back of the machine. Then,
connect the cable to your network.
d Lift the scanner cover to release the lock a.
Gently push the scanner cover support
down b and close the scanner cover c.
25
Connect the power cord
a Connect the power cord.
Note
If both USB and LAN cables are being used,
guide both cables through the trench with one on
top of the other.
Important
Make sure that the cable does not restrict the
cover from closing, or an error may occur.
1
3
2
Important
If you have previously set up your machine for
a wireless network and then want to set it up
on a wired network, you should check that the
machine’s Network I/F is set to Wired LAN.
The wireless network interface will become
inactive with this setting.
On your machine, press MENU.
Press a or b to display Network and press
Network.
Press Network I/F.
Press Wired LAN.
Press Stop/Exit.
