ASSEMBLY AND CONNECTIONS
Paper Capacity of Multi-purpose Sheet Feeder
Multi-purpose Sheet Feeder:
Up to 0.87 inch (22 mm) in height (up to the mark) Approx. 200 sheets of
20 lb. (75 g/m
2
) or 50 sheets of 42 lb. (158 g/m
2
) Letter/A4 paper, or 10
envelopes
Output Tray:
Approx. 50 sheets of 20 lb. (75 g/m
2
) Letter/A4 paper
Cut Sheet Envelopes
Basis Weight 17 to 42 lb.
(64 to 158 g/m
2
)
20 to 24 lb.
(75 to 90 g/m
2
)
single thickness
Caliper ±0.003 to ±0.008 in.
(0.08 to 0.2 mm)
0.0033 to 0.0058 in.
(0.084 to 0.14 mm)
single thickness
Moisture Content 4% to 6% by weight 4% to 6% by weight
Smoothness 100 to 250 (Sheffield) 100 to 250 (Sheffield)
Note
Recommended Paper Types:
Cut sheet: Xerox 4200
Label: Avery laser label or equivalent
Transparency: 3M CG3300 for laser printers or equivalent
