Quick Start Manual

1 - 3 INTRODUCTION
FAX-2800, FAX-2900 and FAX-3800 Control Panel Overview
1Liquid Crystal Display (LCD)
The LCD displays messages to help you
set up and operate your FAX.
2Shift
Accesses the second number stored on
each One Touch key (5-8).
3One Touch Keys:
These 4 keys give you instant access to
8 previously stored auto dial numbers.
4Copy Keys:
Enlarge/Reduce
Lets you reduce or enlarge copies
depending upon the ratio you select.
Options
You can quickly and easily select
temporary settings (for the next copy
only).
Copy
Makes a copy.
5Redial/Pause
Redials the last number called. Also
inserts a pause in auto dial numbers.
6Reports
Accesses the Reports menu so you can
select a report to print: Help List, Auto
Dial, Fax Activity, Transmission
Verification and User Settings.
7Dial Pad
Use to dial phone and fax numbers and
as a keyboard for entering information
into the FAX.
(For Canada Only): The # key lets you
switch the dialing type during a
telephone call from PULSE to TONE.
8Hook/Hold
Lets you dial telephone and fax numbers
without lifting the handset.
—OR—
Lets you place telephone calls on hold.
9Search/Speed Dial
Lets you look up numbers stored in the
dialing memory. Also lets you dial
stored phone numbers.
33
4
1
2 12
5 9
6 8 107
11
(FAX-2800)
