4.2.3 Read Mode
The current mode is shown in the last line. To change the mode, select the
requested mode with help of the cursor buttons and activate the mode by pressing
the ‚Select’ button.
The active mode is shown under item ‚active’.
auto. send: After reading the FOUP-ID the ScanID establishes a connection
to a host data base automatically and sends the FOUP-ID in
message S3F81.
trig. send: After reading the FOUP-ID the information is shown on the
display. The operator can decide whether he establishes a
connection to the host or not by pressing the ‚Select’ button or
not.
not send: After reading the FOUP-ID the information is shown on the
display. The ScanID is not able to establish a connection to the
host.
! The red colored modes are not available for this type !
Read Mode
auto. send
trig. send
not send
active: not send
