110 Brocade Network Advisor REST API Guide
53-1003160-01
Summary data
5
URIs for SCSI measures
<BASE_URI>/resourcegroups/rgkey/scsireadframecount?timeline=<value>×cope=<value>&limit=<value>&
descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/scsireadframecount?timeline=<value>×cope=<value>
&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/fcswitches/fcskey/scsireadframecount?timeline=<value>&ti
mescope=<value>&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcswitches/fcskey/scsireadframecount?timeline=<value>×cope=<value
>&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/scsiwriteframecount?timeline=<value>×cope=<value>&limit=<value>&
descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/scsiwriteframecount?timeline=<value>×cope=<value>
&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/fcswitches/fcskey/scsiwriteframecount?timeline=<value>&ti
mescope=<value>&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcswitches/fcskey/scsiwriteframecount?timeline=<value>×cope=<valu
e>&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/scsireadframerate?timeline=<value>×cope=<value>&limit=<value>&d
escending=<value>
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/scsireadframerate?timeline=<value>×cope=<value>&li
mit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/fcswitches/fcskey/scsireadframerate?timeline=<value>&tim
escope=<value>&limit=<value>&descending=<value>
<BASE_URI>/resourcegroups/rgkey/fcswitches/fcskey/scsireadframerate?timeline=<value>×cope=<value>
&limit=<value>&descending=<value>
SCSI Read Data Rate (mbps) SCSI scsireaddatarate
SCSI Write Data Rate (mbps) SCSI scsiwritedatarate
Transmit Frame Count (frames) Frame txframecount count
Receive Frame Count (frames) Frame rxframecount count
Transmit Frame Rate (f/s) Frame txframerate
Receive Frame Rate (f/s) Frame rxframerate
Transmit Word Count (bytes) Frame txwordcount count
Receive Word Count (bytes) Frame rxwordcount count
Transmit Throughput (mbps) Frame txthroughput
Receive Throughput (mbps) Frame rxthroughput
Average Transmit Frame Size (bytes) Frame avgtxframesize
Average Receive Frame Size (bytes) Frame avgrxframesize
Generator Transmit Frame Count
(frames)
Frame generatortxframecount count
Generator Receive Frame Count
(frames)
Frame generatorrxframecount count
Mirrored Frames Count (frames) Frame mirroredframescount count
Mirrored Transmit Frames (frames) Frame mirroredtxframes count
Mirrored Receive Frames (frames) Frame mirroredrxframes count
TABLE 7 Mapping of the Top N and Bottom N traffic flow summary URIs to the specific measures
Measure Type URI Units
