Summary data
5
Product summaries
Retrieves URIs for retrieving product summary data.
Depending on monitor and measure charateristics, there are various product summaries. The
URIs in the following table return a list of URIs for the possible product summaries in the specified
context.
You can use the returned URIs to get specific product-related summary data, such as Top N,
Bottom N, or Distribution data for a specific product measure.
GET URIs
Path parameters
Notes
• The response schema is SummariesResponse.
• The class name of the summary returned is also in the response.
Top N and Bottom N product summary URIs
The following table shows the mapping of the URIs to the specific measures.
URI Description
<BASE_URI>/resourcegroups/rgkey/productsummaries Retrieves product summary data for the specified
resource group.
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/pro
ductsummaries
Retrieves product summary data for the specified
FC fabric.
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/fcs
witches/fcskey/productsummaries
Retrieves product summary data for the specified
FC switch.
<BASE_URI>/resourcegroups/rgkey/fcswitches/fcskey/p
roductsummaries
Retrieves product summary data for the specified
FC switch in the context of the specified FC fabric.
Name Description
rgkey Resource group identifier.
fcfkey FC fabric identifier.
fcskey FC switch identifier.
TABLE 5 Mapping of Top N and Bottom N product summary URIs to specific measures
Measure URI Units
Memory Utilization Percentage memoryutilpercentage %tage
CPU Utilization Percentage cpuutilpercentage %tage
Temperature temperature degrees C
Fan Speed fanspeed rpm
Response Time responsetime seconds
System Up Time systemuptime seconds
