Summary data
5
Out-of-range violations summary
Retrieves OutOfRange violations summary data.
GET URIs
Path parameters
URI Description
<BASE_URI>/resourcegroups/rgkey/outofrangeviolation
ssummary?timeline=<value>×cope=<value>&port
scope=<value>
Retrieves OutOfRange violations summary data for
the specified resource group.
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/out
ofrangeviolationssummary?timeline=<value>×cop
e=<value>&portscope=<value>
Retrieves OutOfRange violations summary data for
the specified FC fabric.
<BASE_URI>/resourcegroups/rgkey/fcswitches/fcskey/o
utofrangeviolationssummary?timeline=<value>×co
pe=<value>&portscope=<value>
Retrieves OutOfRange violations summary data for
the specified FC switch.
<BASE_URI>/resourcegroups/rgkey/fcports/fcpkey/outo
frangeviolationssummary?timeline=<value>×cope
=<value>&portscope=<value>
Retrieves OutOfRange violations summary data for
the specified FC port.
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/fcs
witches/fcskey/outofrangeviolationssummary?timeline=
<value>×cope=<value>&portscope=<value>
Retrieves OutOfRange violations summary data for
the specified FC switch. This specified switch is under
a specific fabric across all the resource groups.
<BASE_URI>/resourcegroups/rgkey/fcfabrics/fcfkey/fcs
witches/fcskey/fcports/fcpkey/outofrangeviolationssum
mary?timeline=<value>×cope=<value>&portscope
=<value>
Retrieves OutOfRange violations summary data for
the specified FC port under the specified switch in
the context of the specified fabric.
<BASE_URI>/resourcegroups/rgkey/fcswitches/fcskey/f
cports/fcpkey/outofrangeviolationssummary?timeline=<
value>×cope=<value>&portscope=<value>
Retrieves OutOfRange violations summary data for
the specified FC port under the specified switch.
Name Description
rgkey Resource group identifier.
fcfkey FC fabric identifier.
fcpkey FC fabric port identifier.
fcskey FC switch identifier.
