Appendix
C
Specifications
Physical Characteristics
Ports
12 combination SFP/RJ-45 ports, 10/100/1000 Mbps, with auto-negotiation
1 1000BASE-T management port
Network Interface
Ports 1-12: RJ-45 connector, auto MDI/X
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
1000BASE-T: RJ-45 (100-ohm, UTP or STP cable; Category 5 or 5e)
*Maximum Cable Length - 100 m (328 ft)
Buffer Architecture
4 Mbit packet buffer
Aggregate Bandwidth
24 Gbps
Switching Database
16K MAC address entries, 1024 static MAC addresses
LEDs
System: Power, Diag, Mgmt, Major Alarm, Minor Alarm
Port: status (link, speed, and activity)
Port: SFP present
Weight
3.2 kg (7.5 lbs)
