ServerIron ADX Security Guide 131
53-1002440-03
DDoS protection
5
Configuring a rule for IPv6 ICMP types
ServerIron ADX has a set of built-in rules to manage IPv6 icmp types. In this case, the rule
command is used with a <icmp-option> variable specified in Table 16.
The following example configures the "filter4" security filter with a rule to drop packets that
acontain the icmpv6-option type echo-reply.
ServerIronADX(config)# security filter filter4
ServerIronADX(config-sec-filter4)#rule icmp-type echo-reply drop
Syntax: [no] rule ip-option <icmpv6-type> [log | no-log] [drop | no-drop]
The <ipv6-type> variable is specified as one of the options described in Table 16.
The log parameter directs the ServerIron ADX to drop traffic on the bound interface that matches
the rule specified by the configured <icmpv6-type>. The no-log parameter disables this function.
The drop parameter directs the ServerIron ADX to drop traffic on the bound interface that matches
the rule specified by the configured <icmpv6-type>. The no-drop parameter disables this function
icmp-type router-advertisement icmp type 9: router-advertisement
icmp-type r outer-selection icmp type 10: router-selection
icmp-type source-quench icmp type 4: source-quench
icmp-type time icmp type 11: time-exceeded
icmp-type timestamp icmp type 13: timestamp
icmp-type timestamp-reply icmp type 14: timestamp-reply
TABLE 15 icmp option types and descriptions
TABLE 16 ICMPv6 types and descriptions
Attack Type Description
cpa ICMP type 149: Certification Path Advertisement.
cps ICMP type 148: Certification Path Solicitation
echo-reply ICMP type 129: echo-reply
echo-request ICMP type 148: echo-request
mra ICMP type 151: Multicast Router Advertisement
mrs ICMP type 152: Multicast Router Solicitation
mrt ICMP type 153: Multicast Router Termination
neighbor-advertisement ICMP type 136: neighbor-advertisement
neighbor-solicitation ICMP type 135: neighbor-solicitation
private ICMP type 200: Private experimentation
private1 ICMP type 201: Private experimentation
redirect-message ICMP type 137: redirect-message
