qos-mapping
Wireless configuration commands
Configures QoS mappings between the wired and wireless domains
Supported in the following platforms:
• Mobility RFS4000 Controller
• Mobility RFS6000 Controller
• Mobility RFS7000 Controller
Syntax
qos-mapping [wired-to-wireless|wireless-to-wired]
qos-mapping wired-to-wireless [dot1p <0-7>|dscp <0-63>]
[<0-7>|tid0|tid1|tid2|tid3|tid4|tid5|tid6|tid7]
qos-mapping wireless-to-wired [tid0|tid1|tid2|tid3|tid4|tid5|tid6|tid7] dot1p
<0-7>
Parameters
Example
RFController(config-wireless)#qos-mapping wireless-to-wired background dot1p 5
RFController(config-wireless)#
wired-to-wireless [dot1p
<0-7>|dscp <0-63>]
[<0-7>|tid0|tid1|tid2|tid3
|
tid4|tid5|tid6|tid7]
Mappings used while controlling wired traffic over the air .
• dot1p <0-7> – Configures the mapping of 802.1p tags to
access categories. You can specify more than one 802.1p
tags with in the range 0 and 7.
• dscp <0-63> – Configures the mapping of DSCP values to
access categories. You can specify more than one DSCP
values in the range 0-63.
• tid0, tid3– best effort category traffic
• tid1, tid2 – background category traffic
• tid4, tid5 – video traffic category traffic
• tid6, tid7 – voice traffic category traffic
wireless-to-wired
[tid0|tid1|tid2|tid3|
tid4|tid5|tid6|tid7]
dot1p <0-7>
Mappings used while controlling wireless traffic to the wired side.
• tid0, tid3– best effort category traffic
• tid1, tid2 – background category traffic
• tid4, tid5 – video traffic category traffic
• tid6, tid7 – voice traffic category traffic
• dot1p <0-7> – Configures the mapping of 802.1p tags to
access categories. You can specify more than one 802.1p
tags with in the range 0 and 7.
