Extended ACL config commands
14
Parameters
8021p
<vlan-priority-value>
Sets the 802.1p VLAN user priority value to <vlan-priority-value>
(0-7).
dscp
<dscp-codepoint-value>
Sets the Differentiated Services Code Point code-point value to
<dscp-codepoint-value> (0-63)
tos <tos-value> Sets the TOS value to <tos-value>. The least significant two bits of
the <tos-value> must be 0.
ip
[<source-IP/Mask>|any|ho
st <IP>] [<dest-IP/Mask>|
any|host <IP>] {log}
{rule-precedence
<1-5000>}
Use with mark command to mark a packet.
• ip – Specifies an IP (to match to a protocol)
• <source-IP/Mask>|any|host <IP> – The keyword
<source-IP> is the source IP address of the network or host
in dotted decimal format. The <mask> is the network mask.
For example, 10.1.1.10/24 indicates the first 24 bits of the
source IP is used for matching.
• any – any is an abbreviation for a source IP of 0.0.0.0 and
source-mask bits equal to 0
• host – host is an abbreviation for the exact source <IP>
(A.B.C.D format) and source-mask bits equal to 32
• <dest-IP/Mask>|any|host <IP> – Defines the destination
host IP address or destination network address.
• log – Generates log messages when the packet coming from
the interface matches an ACL entry. Log messages are
generated only for router ACLs.
• rule-precedence <1-5000> – Defines an integer value
between 1-5000. This value sets the rule precedence in the
ACL.
icmp
[<source-IP/mask>|any|ho
st <IP>]
[<dest-IP/Mask>|any|
host <IP>] {<ICMP-type>
{<ICMP-code>}} {log}
{rule-precedence
<1-5000>]}
Use with the mark command to mark ICMP packets
• deny – Rejects ICMP packets
• icmp – Specifies ICMP as the protocol
• [<source-IP/mask>|any|host <IP>] – The source
<source-IP> is the source IP address of the network or host
(in dotted decimal format). The <Mask> is the network mask.
For example, 10.1.1.10/24 indicates the first 24 bits of the
source IP is used for matching.
• any – any is an abbreviation for a source IP of 0.0.0.0 and
source-mask bits equal to 0
• host – host is an abbreviation for exact source (A.B.C.D) and
source-mask bits equal to 32
• [<dest-IP/Mask>|any|host <IP>] – Defines the destination
host IP address or destination network address
• <ICMP-type> {<ICMP-code>} – Sets the ICMP type value
<ICMP-type> from 0 to 255, and is valid only for ICMP. The
ICMP code value <ICMP-code> is from 0 to 255, and is valid
only for protocol type icmp.
• log – Generates log messages when the packet coming from
the interface matches the ACL entry. Log messages are
generated only for router ACLs.
• rule-precedence <1-5000> – Defines an integer value
between 1-5000. This value sets the rule precedence in the
ACL.
