418 Brocade Mobility RFS4000, RFS6000 and RFS7000 CLI Reference Guide
53-1001931-01
Interface config commands
12
port-channel
Interface config commands
Selects the load-balance criteria of an aggregated port
Supported in the following platforms:
• Mobility RFS7000 Controller
• Mobility RFS4000 Controller
NOTE
This command is not supported on the Mobility RFS6000 Controller.
Syntax
port-channel load-balance [src-dst-ip|src-dst-mac]
Parameters
Usage Guidelines
Use this command to configure and set load balance on the aggregated port using
(config-if)
static-channel-group
.
Example
The following example creates a channel group 1, with interface ge1 and ge 2:
RFController(config)#interface ge1
RFController(config-if)#static-channel-group 1
RFController(config)#interface ge2
RFController(config-if)#static-channel-group 1
The following example defines the load balance based on the IP or MAC address:
RFController(config)#interface sa1
RFController(config-if)#port-channel load-balance src--dst-ip
RFController(config-if)#
Configuring a port aggregation
Use static-channel-group and port-channel for configuring port aggregation. Follow the steps
below to configure port aggregation:
1. Create a static channel group for port aggregation and associate an interface with it.
RFController(config)#interface ge 1
RFController(config-if)#static-channel-group 1
2. Execute show static-channel-group and ensure the virtual static aggregation
sa 1 has been created and associated with
ge 1.
load-balance
[src-dst-ip|src-dst-mac]
Sets load-balancing for port channel
• src-dst-ip – Defines the Source and Destination IP address
based on the current load balancing
• src-dst-mac – Sets the Source and Destination MAC
address based on the load balancing
