Global Configuration commands
5
Usage Guidelines
1. Use the
no command along with ip to undo any IP based configuration.
[no] ip(access-list|default-gateway|dos|dhcp|domain-lookup|
domain-name|http|local|name-server|nat|route|routing|ssh|telnet)
2. When using the ip access-list parameter, enter the following contexts:
• ext-nacl – Extended ACL. For more information, see
Chapter 14, Extended ACL Instance
• std-nacl – Standard ACL. For more information, see
Chapter 15, Standard ACL Instance
• dhcp – DHCP Server instance. For more information, see
Chapter 17, DHCP Server Instance
• tcp -max-incomplete –Configures the maximum half-open
TCP connections in the system
• high <1-1000> – Sets the upper threshold value
between 1 and 1000
• low <1 - 1000> – Sets the lower threshold value
between 1 and1000
igmp snooping
{[querier|unknown-multicas
t-fwd|vlan]}
Configures IGMP Snooping parameters.
• unknown-multicast-fwd – Optional. Forwards packets from
unregistered multicast servers
• querier
{[address|max-response-time|query-interval|timer|version]
}}– Configures IGMP querier. All options are optional
• address <IP> – Sets GMP querier source IP address
• max-response-time <1-25> – Sets IGMP querier
maximum response time in seconds
• query-interval <1-18000> – Sets IGMP querier query
interval
• timer expiry <60-300> – Sets querier other querier time
out in seconds to a value in the range 60 to 300
• version <1-3> – Sets IGMP version
• vlan [<1-4094>|<vlan-list>]
{mrouter|querier|unknown-multicast-fwd]}
– Identifies the
vlan to use. All options are optional
• vlan <1-4094>|<vlan-list>] – Sets the vlan to use for
IGMP Snooping
• <1-4094> – A single VLAN ID
• <vlan-list> – A list of VLAN IDs
• mrouter [interface <interface> |learn pim-dvmrp]
– Sets information for Multicast router
• interface <interface> – Gigabit Ethernet interfaces
to be configured. <interface> can be a single
interface or a list of interfaces
• learn pim-dvmrp – The multicast controller
learning protocol using PIM-DVMRP protocol
• querier
{[address|max-response-time|query-interval|time
r|version]}} – Sets IGMP querier for the selected
VLAN interface
• unknown-multicast-fwd – Forwards packets from
unregistered multicast servers for this VLAN
