Use and Care Guide

SPECIFICATION SHEET
PRODUCT SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
PROJECT REMARKS
LOCATION
MODEL NO.
Q
TY.
SUBMITTED BY
DAT E
BROAN-NUTONE CANADA INC., MISSISSAUGA, ONTARIO WWW.BROAN.CA 1-888-882-7626
B59000 SERIES
B5936d111014
34⅞”
23
9
⁄
16
”
11⅛”
HK0102A
AIR FLOW PERFORMANCE
DIMENSIONSSPECIFICATIONS
HG0071A
STATIC PRESSURE (IN. W.G.)
AIR FLOW RATE (CFM)
0.0
0.5
1.0
1.5
2.0
2.5
0 100 200 300 400 500
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and procedures prescribed by the Home Ventilating
Institute, for off-the-shelf products, as they are available to consumers. Product performance is rated at 0.1 in. (2.54 mm)
static pressure, based on tests conducted in a state-of-the-art test laboratory. Sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
* OPTIONAL ARP6 AIR FLOW REDUCER (LIMITS THE
AIRFLOW OF THE HOOD UNDER 300 CFM).
MODEL B59000 SERIES
VOLTS 120 VAC
H
Z 60
A
MPS 3.3
CFM (H
IGH SPEED) 450*
CFM (L
OW SPEED)190
SONES (HIGH SPEED) 8.5
S
ONES (LOW SPEED) 2.5
D
UCTING SIZE 6" ROUND
4 HALOGEN BULBS
TYPE JC, 20 W, 12 V
WITH G4 BASE
WARRANTY 1 YEAR
