Datasheet

5
OUTPUT POWER – P
S
, INPUT CURRENT – I
S
0
0
T
S
– CASE TEMPERATURE – °C
200
600
400
25
HCPL-J314
800
50 75 100
200
150 175
P
S
(mW)
125
100
300
500
700
I
S
(mA)
IEC/EN/DIN EN 60747-5-2 Insulation Characteristics
Description Symbol Characteristic Unit
Installation classication per DIN VDE 0110/1.89, Table 1
for rated mains voltage ≤ 150 V
rms
I - IV
for rated mains voltage ≤ 300 V
rms
I - IV
for rated mains voltage ≤ 600 V
rms
I - III
Climatic Classication 55/100/21
Pollution Degree (DIN VDE 0110/1.89) 2
Maximum Working Insulation Voltage V
IORM
891 V
peak
Input to Output Test Voltage, Method b*
V
IORM
x 1.875 = V
PR
, 100% Production Test with t
m
= 1 sec, V
PR
1670 V
peak
Partial discharge < 5 pC
Input to Output Test Voltage, Method a*
V
IORM
x 1.5 = V
PR
, Type and Sample Test, t
m
= 60 sec, V
PR
1336 V
peak
Partial discharge < 5 pC
Highest Allowable Overvoltage (Transient Overvoltage t
ini
= 10 sec) V
IOTM
6000 V
peak
Safety-limiting values – maximum values allowed in the event of a failure.
Case Temperature T
S
175 °C
Input Current** I
S,INPUT
400 mA
Output Power** P
S, OUTPUT
1200 mW
Insulation Resistance at T
S
, V
IO
= 500 V R
S
>10
9
Ω
*Refer to the optocoupler section of the Isolation and Control Components Designer’s Catalog, under Product Safety Regulations section, IEC/
EN/DIN EN 60747-5-2 for a detailed description of Method a and Method b partial discharge test proles.
** Refer to the following gure for dependence of P
S
and I
S
on ambient temperature.
