Datasheet

2
Selection Guide
Package Type Part Number Number of Channels
8-pin DIP (300 Mil) HCPL-J314 1
SO16 HCPL-314J 2
Note: Please refer to HCPL-314J datasheet for more details
Ordering Information
HCPL-J314 is UL Recognized with 3750 Vrms for 1 minute per UL1577.
Part
Number
Option
Package
Surface
Mount
Gull
Wing
Tape
& Reel
IEC/EN/DIN
EN 60747-5-2 Quantity
RoHS
Compliant
Non RoHS
Compliant
HCPL-J314
-000E No option
300mil
DIP-8
X 50 per tube
-300E #300 X X X 50 per tube
-500E #500 X X X X 1000 per reel
To order, choose a part number from the part number column and combine with the desired option from the option
column to form an order entry.
Example 1: HCPL-J314-500E to order product of 300 mil DIP Gull Wing Surface Mount package in Tape and Reel
packaging with IEC/EN/DIN EN 60747-5-2 Safety Approval in RoHS compliant.
Example 2: HCPL-J314 to order product of 300 mil DIP package in tube packaging with IEC/EN/DIN EN 60747-5-2 Safety
Approval and non RoHS complaint
Option data sheets are available. Contact your Avago sales representative or authorized distributor for information.
Remarks: The notation ‘#XXX’ is used for existing products, while (new) products launched since 15th July 2001 and
RoHS compliant option will use ‘-XXXE‘.
