Datasheet

7
Absolute Maximum Ratings
Parameter Symbol Min. Max. Units
Storage Temperature T
S
–55 125 °C
Ambient Operating Temperature
[1]
T
A
–40 85 °C
Supply Voltages V
DD1
, V
DD2
0 6.0 Volts
Input Voltage V
I
–0.5 V
DD1
+0.5 Volts
Output Voltage V
O
–0.5 V
DD2
+0.5 Volts
Average Output Current I
O
10 mA
Lead Solder Temperature 260°C for 10 sec., 1.6 mm below seating plane
Solder Reow Temperature Prole See Solder Reow Temperature Prole Section
Recommended Operating Conditions
Parameter Symbol Min. Max. Units
Ambient Operating Temperature T
A
–40 85 °C
Supply Voltages V
DD1
, V
DD2
4.5 5.5 V
Logic High Input Voltage V
IH
2.0 V
DD1
V
Logic Low Input Voltage V
IL
0.0 0.8 V
Input Signal Rise and Fall Times t
r,
t
f
1.0 ms
Electrical Specications
Test conditions that are not specied can be anywhere within the recommended operating range.
All typical specications are at T
A
= +25°C, V
DD1
= V
DD2
= +5 V.
Parameter Symbol Min. Typ. Max. Units Test Conditions
Logic Low Input Supply Current
[2]
I
DD1L
7 10 mA V
I
= 0 V
Logic High Input Supply Current
[2]
I
DD1H
1.8 3 mA V
I
= V
DD1
Output Supply Current I
DD2L
12.5 17.5 mA
I
DD2H
12 16.5 mA
Input Current I
I
–10 10 µA
Logic High Output Voltage V
OH
4.4 5.0 V I
O
= –20 µA, V
I
= V
IH
4.0 4.8 V I
O
= –4 mA, V
I
= V
IH
Logic Low Output Voltage V
OL
0 0.1 V I
O
= 20 µA, V
I
= V
IL
0.5 1.0 V I
O
= 4 mA, V
I
= V
IL
