Datasheet

7
Recommended Operating Conditions
Parameter Symbol Min. Max. Units
Power Supply Voltage (V
CC
- V
EE
) 15 30 Volts
Input Current (ON) I
F(ON)
7 16 mA
Input Voltage (OFF) V
F(OFF)
-3.6 0.8 V
Operating Temperature T
A
-40 100 °C
Absolute Maximum Ratings
Parameter Symbol Min. Max. Units Note
Storage Temperature T
S
-55 125 °C
Operating Temperature T
A
-40 100 °C
Average Input Current I
F(AVG)
25 mA 1, 16
Peak Transient Input Current I
F(TRAN)
1.0 A
(<1 µs pulse width, 300 pps)
Reverse Input Voltage V
R
5 Volts
“High” Peak Output Current I
OH(PEAK)
0.6 A 2, 16
“Low” Peak Output Current I
OL(PEAK)
0.6 A 2, 16
Supply Voltage (V
CC
- V
EE
) 0 35 Volts
Output Voltage V
O(PEAK)
0 V
CC
Volts
Output Power Dissipation P
O
250 mW 3, 16
Total Power Dissipation P
T
295 mW 4, 16
Lead Solder Temperature 260°C for 10 sec., 1.6 mm below seating plane
Solder Reow Temperature Prole See Package Outline Drawings Section
Insulation and Safety Related Specications
Parameter Symbol HCPL-3150 HCPL-315J Units Conditions
Minimum External L(101) 7.1 8.3 mm Measured from input terminals
Air Gap to output terminals, shortest
(External Clearance) distance through air.
Minimum External L(102) 7.4 8.3 mm Measured from input terminals
Tracking to output erminals, shortest
(External Creepage) distance path along body.
Minimum Internal 0.08 ≥0.5 mm Through insulation distance
Plastic Gap conductor to conductor.
(Internal Clearance)
Tracking Resistance CTI ≥175 ≥175 Volts DIN IEC 112/VDE 0303 Part 1
(Comparative Tracking
Index)
Isolation Group IIIa IIIa Material Group (DIN VDE 0110,
1/89, Table 1)
Option 300 - surface mount classication is Class A in accordance wtih CECC 00802.
