Electrical Specications
0°C ≤T
A
≤70°C, 4.75 V ≤V
CC
≤5.25 V, 4 mA ≤I
F(ON)
≤8 mA, 0 V ≤V
F(OFF)
≤0.8 V. All typicals at T
A
= 25°C, V
CC
= 5 V, I
F(ON)
= 6.0
mA, V
F(OFF)
= 0 V, except where noted. See Note 11.
Device
Parameter Symbol HCPL- Min. Typ.* Max. Units Test Conditions Fig. Note
Logic Low Output Voltage V
OL
0.5 V I
OL
= 8.0 mA (5 TTL Loads) 1
Logic High Output V
OH
2.4 V I
OH
= -4.0 mA 2
Voltage 2.7 I
OH
= -0.4 mA
Output Leakage Current I
OHH
100 µA V
O
= 5.25 V, V
F
= 0.8 V
Logic High Enable Current V
EH
2400 2.0 V
Logic Low Enable Voltage V
EL
2400 0.8 V
Logic High Enable I
EH
2400 20 µA V
E
= 2.4 V
100 V
E
= 5.25 V
Logic Low Enable Current I
EL
2400 - 0.28 -0.4 mA V
E
= 0.4 V
Logic Low Supply Current I
CCL
2400 19 26 mA V
CC
= 5.25 V, V
E
= 0 V,
I
O
= Open
2430 34 46 V
CC
= 5.25 V, I
O
= Open
Logic High Supply I
CCH
2400 17 26 mA V
CC
= 5.25 V, V
E
= 0 V,
Current I
O
= Open
2430 32 42 V
CC
= 5.25 V, I
O
= Open
High Impedance State I
CCZ
2400 22 28 mA V
CC
= 5.25 V, V
E
= 5.25 V
Supply Current
High Impedance State I
OZL
2400 20 µA V
O
= 0.4 V V
E
= 2 V
I
OZH
20 µA V
O
= 2.4 V
I
OZH
100 µA V
O
= 5.25 V
Logic Low Short Circuit I
OSL
52 mA V
O
= V
CC
= 5.25 V, 2
Output Current I
F
= 8 mA
Logic High Short Circuit I
OSH
-45 mA V
CC
= 5.25 V, I
F
= 0 mA, 2
Output Current V
O
= GND
Input Current Hysteresis I
HYS
0.25 mA V
CC
= 5 V 3
Input Forward Voltage V
F
1.1 1.3 1.5 T
A
= 25°C I
F
= 8 mA
1.0 1.55 4
Input Reverse Breakdown BV
R
3.0 5.0 V T
A
= 25°C I
R
= 10 µA
2.0
Temperature ∆V
F
-1.44 mV/°C I
F
= 6 mA 4
Coecient of
Forward Voltage
Input Capacitance C
IN
20 pF f = 1 MHz, V
F
= 0 V
*All typical values at T
A
= 25°C and V
CC
= 5 V, unless otherwise noted.
Current
Voltage
∆T
A
Output Current
