Section 4: Operation 4-17
Moseley SL9003Q 602-12016 Revision G
Function Settings Summary
Unit No
1-255 Defines Unit # for network ID
MAIN TITLE
TRANSMITTER
RECEIVER
TRANSCEIVER
T1
DTV Link
NXE1
DS3 TX
DS3 RX
DS3 XC
EXP RX
EXP TX
Determines main menu display and affects screen menu
selection of modules
Redundant
OFF
ON
Chooses redundant supply option
IP MSB
IP
IP LSB
SNM MSB
SNM
SNM LSB
GW MSB
GW
GW LSB
1-255 IP address settings (w/ SNMP option installed)
Calc Ber
always
RMT
LOC
IP address settings (w/ SNMP option installed)
Synth Doubler
Yes
No
Setting for > 2 GHz operation
DTV2
YES
NO
EXP
Option setting
First Stage
-xxx to +xxx Option setting
Mapping
0-3 External I/O Option setting
High Speed
Yes
No
High Speed Modem Option
Lo/Hi Change?
Yes
No
Locks out user from changing the Low/High-side LO
setting
