ADC-1 Plus Installation and Operation Manual
SPECIFICATIONS
Specifications
Analog Input Level 0dBu to +24dBu. +4dBu analog input provides -20dBfs
AES output when adjusted with the front panel trimmers.
Analog Input Impedance 10K Ω balanced.
Frequency Response 10 to 20kHz +/- 0.5dB.
Distortion <.001%THD / IMD
Noise <108dB Ref
AES Output Impedance 110 Ω , balanced.
Word clock input impedance 75 Ω , balanced
Word clock input level 5 volts
Word clock PLL input range 32 to 96kHz
Connectors Analog inputs, AES output connections: XLR connectors,
Word Clock; BNC
Power Requirements Universal switching power supply with domestic AC con-
nector supplied.
+/-15 VDC 400mA output with 3-pin AMP-style latching
power connector.
Size: 5.66" x 7.00” x 1.58", Painted aluminum chassis w/ 4 - 4-40
mounting holes.
Weight: 2.0 lb.
Options: RA-1 rack shelf, holds three units (1-RU) / Filler panels
supplied.
International connectors optional.
WEBSITE:
Visit our web site for
product updates and
additional information.
