Adjusting Buckle Position
Removing the Buckle
Unbuckle the harness by
1
pressing the release button
and pulling the tongues.
Re-threading the Buckle
IMPORTANT: Select the slot
closest to, but not under the child.
Turn and push the buckle 1
retainer through the slot in the
cover and child seat shell.
Locate the buckle retainer on
2
the bottom of the child seat.
Slide the buckle retainer up
3
or down to release it from the
child seat shell.
Pull the buckle retainer away
4
from the child seat to loosen.
Turn and push the buckle
5
retainer through the slot in the
child seat shell.
Pull the buckle retainer 2
through the slots in the cover
and child seat shell to the
bottom of the child seat.
Pull the buckle away from the
4
child seat until tight.
Ensure that the buckle strap is *
not twisted.
2
Pull the buckle retainer 6
through the slots in the child
seat shell and cover to the top
of the child seat.
Slide the buckle retainer back
3
into place to hold it against
the child seat shell.
