Een luchtverwarmer uit de Allure-serie wordt geleverd voor
aardgas.
2.2 Technische informatie
Uitvoering Hoofdstuk 2
Technische gegevens
Type
B-16 HR(D)
1350
B-16 HR(D)
2100
B-16 HR(D)
3000
B-25 HR(D)
2100
B-25 HR(D)
3400
B-40 HR(D)
3400
Instelbare netto capaciteit [kW] 4 - 16 6 - 25 9,5 - 39,5
Nominale belasting
bovenwaarde [kW]
4,08 - 17,20 6,10 - 26,80 9,65 - 42,40
Nominaal elektrisch opgenomen
vermogen [kW]
0,19 0,26 0,60 0,26 0,60 0,60
Instelbare luchthoeveelheid [m
3
/h] 300 - 1350 450 - 2100 750 - 3000 450 - 2100 450 - 3400 750 - 3400
Instelling ventilator regeling [°C]
Ventilator in bij vlam
Ventilator uit tussen 20 - 30
Maximaal beveiliging [°C] 100
Breedte [mm] 400 500 600 500 600 600
Hoogte [mm] 1200
Diepte [mm] 740
Gewicht [kg] 74 78 82 83 87 92
Voedingsspanning [V~/Hz] 230/50
Beschermingsgraad IP30
Diameter hoofdinspuiter [mm] 6 x Ø2,8 6 x Ø3,8 6 x Ø4,8
Gasaansluiting [”] 1/2”
Condenswaterafvoer
aansluiting [mm]
32
Rookgasaansluiting [mm] Ø80
Verbrandingsluchtaansluiting [mm] Ø80
Zekering [A]
(Zekering buiten het toestel)
16T (Aanbevolen wordt de voeding aan te sluiten op een aparte eindgroep)
