Datasheet

V1.0

N-Series Superior Night Vision

1.3 Megapixel Bullet Network Camera

▪ N-Series Sony Exmor 1.3M Outdoor Bullet Camera

▪ SmartFocus

to Ease the Zoom and Focus Adjustment Remotely

▪ Motorized Lens / Vari-Focal Lens for Variable Needs

▪ Brickcom WDR Enhancement

Technology inside

▪ Intelligent Multi-Profile Sensor Management

for Different Environments

▪ HDTV Quality ( 720p @ 30fps)

▪ Best for Car-Plate Recognition

▪ Removable IR-cut Filter /Auto Light Sensor for Day and Night

▪ Built-in 3G module and SIM slot for Wireless Connectivity

▪ Two-way Audio/Built-in Micro SD/SDHC Memory Card Slot for Local Storage

▪ 1 DI/DO for External Alarm and Sensor Device

▪ IP67 Outdoor Enclosure Built-in Fan (-40°C ~ 60°C) and Heater

▪ Power over Ethernet

IR LED(24pcs)

LENs

Light Sensor

RJ45 Connector 1 (For Ethernet and High Power PoE)

Antenna Connector

RJ45 Connector 2 (For Audio in/out, RS485, DIDO)

Photo Indication & Dimension Diagram

OB-130N Series Smart Focus

/ WDR Enhancement

PAGE 1
N-Series Superior Night Vision 1.3 Megapixel Bullet Network Camera OB-130N Series Smart Focus® / WDR Enhancement® ▪ N-Series Sony Exmor 1.
PAGE 2
Camera Models Hardware System Audio OB-130Np:1.3M, Motorized Lens OB-132Np:1.3M, Vari-Focal Lens WOB-130Np:1.3M, Motorized Lens, Wireless GOB-130Np:1.3M, Motorized Lens, 3G CPU: 500 MHz Flash: 16M RAM: 128M DDR Image Sensor Sensor Type :1/3" 1.3M Sony CMOS Megapixel sensor Sensor Resolution : 1280x1024/HDTV Lens Minimum Illumination IR Illuminators Lens Type: Board Lens IRIS: F1.4 OB-130Np/WOB-130Np/GOB-130Np Focal Length: 3~10.
PAGE 3
OB-130N Series Lens Type OB-130Np/OB-132Np WOB-130Np GOB-130Np Motorized Lens / Vari-Focal Motorized Lens / Vari-Focal Motorized Lens / Vari-Focal -20°C ~ 60°C/ -40°C ~ 60°C Operating Temperature 802.3af / 802.
