400.100 B1/ B2/ B3 SPP Braided Faucet Connector - Compression Inlet REV 07/13 2013 BrassCraft Mfg.
Product Submittal Form
B1-**A/ B2-**A/ B3-**A Speedi Plumb® PLUS Braided Faucet
Connector - Compression Inlet
Use: For use in potable water distribution systems in accessible locations only
Design Features:
 Engineered polymer braided fibers bend freely without kinking or
crimping
 Reinforced PVC inner hose ensures durability
 Rubber washers provide a large pliable sealing surface and ensure a
long lasting water-tight connection
 8-sided pneumatic crimp provides greater dependability for realible
nut-to-hose connections
 100% No Lead
Operating Specifications:
Temperature: 40°- 140°F, intermittent to 180°F
Pressure: 125 PSI maximum
Tubing Diameter: 0.300” ID (0.550” OD)
MATERIAL SPECIFICATIONS
Inner Hose
Reinforced PVC
Braiding
PVC coated polyester yarn
Barb
Compliant brass
Ferrule
Zinc-plated steel
Nut
Brass, chrome plated or polypropylene
Washer
Rubber
Compression Nut
Brass, chrome plated
Part Listing:
B1-12A F 3/8” compression x 1/2" FIP* x 12” length
B1-16A F 3/8” compression x 1/2" FIP* x 16” length
B1-20A F 3/8” compression x 1/2" FIP* x 20” length
B1-20AU D 3/8” compression x 1/2" FIP* x 20” length connector with 1/2” OD compression &
1/2” iron pipe valve adaptors, carded
For Residential and Commercial Applications
JobName

Engineer/Architect

JobLocation

Wholesaler

SubmittalDate

Contractor

