User`s manual

ManualsBrandsBoss Audio Systems Manualscar TFT monitorsHeadrest Widescreen

HIR70BL

HIR70GR

HIR70TA

7"(178mm)

UNIVERSAL HEADREST WITH

PRE-INSTALLED WIDESCREEN

TFT VIDEO MONITOR

WITH BUILT-IN DUAL

CHANNEL INFRARED AUTO

TRANSMITTER

HIR70BL

HIR70GR

HIR70TA

7"(178mm) UNIVERSAL HEADREST

WITH PRE-INSTALLED WIDESCREEN

TFT VIDEO MONITOR WITH BUILT-IN DUAL

CHANNEL INFRARED AUTO TRANSMITTER

09.2011

Summary of content (6 pages)

PAGE 1
HIR70BL HIR70GR HIR70TA 7"(178mm) UNIVERSAL HEADREST WITH PRE-INSTALLED WIDESCREEN TFT VIDEO MONITOR WITH BUILT-IN DUAL CHANNEL INFRARED AUTO TRANSMITTER HIR70BL HIR70GR HIR70TA 7"(178mm) UNIVERSAL HEADREST WITH PRE-INSTALLED WIDESCREEN TFT VIDEO MONITOR WITH BUILT-IN DUAL CHANNEL INFRARED AUTO TRANSMITTER 09.
PAGE 2
USER’S MANUAL TROUBLESHOOTING Troubleshooting If you experience or performance problems with this product, compare your installation with the electrical wiring diagram on the previous page. If problems persist, read the following troubleshooting tips which may help eliminate the problems. SYMPTOM HIR70BL HIR70GR HIR70TA REMEDY CAUSE Power cord is not properly connected.
PAGE 3
SPECIFICATIONS PRECAUTIONS Please read and observe all warning and instructions in this owner’s manual and those marked on the unit. Retain this booklet for future reference. Power Requirements DC 12V Power Consumption 6W Screen Size 7 inch LED Backlit TFT LCD Screen Format 16:9 Wide Resolution Pixel 800xRGBx480 A/V Inputs Two video & one audio inputs Dimensions (W)13.5x(D)10.59x(H)5.5inch IR Power Requirements DC 12V IR Power Consumption 3W IR Transmitter Frequency A A: Right 2.
PAGE 4
PRECAUTIONS A/V AND POWER CONNECTIONS On a towel or soft cloth, gently place the monitor assembly “face down” on a stable work surface. Using the wires provided, complete the audio, video and power connections in your vehicle as shown in the diagram below. CAUTION Watching the monitor for an extended period of time with the engine turned off may deplete the vehicle’s battery. Quality installations are best performed by qualified and certified installers. Do not cover heater ducts or vents.
PAGE 5
FEATURES AND CONTROLS 1.Power switch OSD 9 1 BRIGHT CONTRAST COLOR TINT SOURCE ROTATE ZOOM LANGUAGE RESET IR 2.V1 switch 3.V2 switch 2 4.Decrease 3 4 5 6 7 8 5.Menu 6.Increase 7.Mode switch 8.Sys switch 9.Remote sensor 1 POWER Press to turn unit ON or OFF. 2 2 A/V SELECT Use this button to switch between Video source1 and Video source 2. 1 3 3 4 5 ZOOM MENU This button enables the on-screen display menu system. Once enabled, this button is used as an ENTER button.
PAGE 6
INSTALLATION INSTALLATION 1 2 1.Tubes could be adjusted from left and right. 50 50 50 2.Tubes could be adjusted from front and back.
