Insert effect parameter functions
Enhancer
By adding sounds that are out-of-phase with the direct
sound, this effect enhances the definition of the sound and
makes it more present in the mix.
Effect On/Off OFF, ON
This parameter turns the enhancer effect on or off.
Sensitivity 0–100
Adjusts the manner in which the enhancer will be applied with
respect to input signals.
Frequency 1.0–10.0 kHz
Adjusts the frequency at which the enhancer will begin to be applied.
The effect will be noticeable in frequencies above the frequency set here.
Mix Level 0–100
Adjusts the amount of phase-shifted sound of the range set by
“Frequency” that is to be mixed with the input.
Low Mix Level 0–100
Adjusts the amount of phase-shifted sound in the low-frequency
range that is to be mixed with the input. The extent of this low-
frequency range is fixed.
Level 0–100
Adjusts the overall volume of the enhanced sound.
Flanger
This algorithm produces a flanging effect, which makes a
sound seem as if it is twisting.
* If the “COSM OD GUITAR AMP” algorithm is selected, this effect can
be used if “FL” is selected for the “FX Select” of the FX. If other than
“COSM OD GUITAR AMP” algorithm is selected, this effect can be
used if “FLANGER” is selected for the “Effect Type” of the Modulation.
Effect On/Off OFF, ON
This parameter turns the flanger effect on or off.
Rate 0–100
Determines the rate of the flanging effect.
Depth 0–100
Determines the depth of the flanging effect.
Manual 0–100
This parameter adjusts the center frequency at which the effect will
be applied.
Resonance 0–100
Determines the amount of resonance (or feedback). Increasing this
value will emphasize the flanging effect, producing a more unusual
sound.
Separation 0–100
This parameter adjusts the diffusion. Large values produce greater
diffusion, and this will be effective when stereo output is used.
■ When “COSM OD GUITAR AMP”
algorithm is selected
Effect Level 0–100
This adjusts the volume of the flanger sound.
Direct Level 0–100
This adjusts the volume of the direct sound.
Foot Volume
Specify the volume between effects. By using an expression
pedal to control the foot volume, you can smoothly change
the volume of the output sound. For a detailed explanation,
see “Using an expression pedal” (p. 84).
Foot Volume On/Off OFF, ON
Switches the foot volume on or off.
Humanizer
This can create human vowel-like sounds.
* This effect can be used in the “COSM OD GUITAR AMP” algorithm
when FX “FX Select” parameter is set to “HU.”
Vowel1
A, E, I, O, U
This selects the first vowel.
Vowel2 A, E, I, O, U
This selects the second vowel.
Rate 0–100
This adjusts the cycle for changing the two vowels.
Depth 0–100
This adjusts the depth of the effect.
Manual 0–100
This determines the point where the two vowels are switched. When it is
set to “50,” vowel 1 and vowel 2 are switched in the same length of time.
When it is set to lower than “50,” the time for vowel 1 is shorter. When it
is set to higher than “50,” the time for vowel 1 is longer.
Level 0–100
This adjusts the volume of the humanizer sound.
