Using insert effects
5. Press [F3] (=>PRM.).
The cursor will jump to the parameter area on the right
of the screen, and you will now be able to change the
parameter settings.
fig.31-03d
6. Move the cursor to the parameter whose setting you
want to change and select a new value using the TIME/
VALUE dial.
7. If you also want to edit other effect blocks, press [F2]
(BLOCK<=) to move the cursor to the left of the screen,
and then repeat Steps 4 and 5.
Note that you can press CURSOR [ ] or [ ] while on a
parameter setting screen to jump to the parameter setting
screen for the next effect block to the left or right, respectively.
8. Press [EXIT/NO] to return to the Effects Patch screen.
fig.31-04d
In order to indicate that the effect settings have been
temporarily changed, the bank number will be displayed
as “*TMP.” If you select a different patch, load a different
song, or turn off the BR-1600CD while “TMP” is being
displayed, all of the patch settings will return to their
previous condition. As it may not be possible to restore
these settings, the appropriate care should be taken.
9. To save your modified settings, carry out the procedure
described in “Saving insert effect settings (Effect Patch
Write)” (p. 81).
Changing the sound of insert
effects using the VALUE knobs
The following four knob icons are displayed on the insert
effects' patch screen.
fig.31-60
The text above each icon indicates the parameter that has
been assigned to it, and the text below each icon indicates the
current value of that parameter.
The value knobs VALUE 1 through VALUE 4 can now be
used to directly edit the values of the corresponding
parameters.
1. Press [EFFECTS].
The Effects Patch screen will appear.
fig.31-01d
2. Move one of the value knobs VALUE 1 through
VALUE 4.
The icon for that knob will change in response to this
movement. In addition, the value of the parameter
assigned to the knob will also change, and this will
modify the sound of the effect accordingly.
3. To save the modified sound, carry out the procedure
described below in “Saving insert effect settings (Effect
Patch Write)” (p. 81).
Changing parameters assigned
to VALUE knobs
Use the following procedure to change the effect parameters
that are assigned to each of the VALUE knobs.
1. Press [EFFECTS].
The Effects Patch screen will appear.
fig.31-01d
2. Move the cursor to the text above the icon whose
parameter assignment is to be changed.
fig.31-61d
3. Select the parameter to be assigned using the TIME/
VALUE dial.
4. To save the settings, carry out the procedure described
below in “Saving insert effect settings (Effect Patch
Write)” (p. 81).
Parameters
Value
Patch number
Bank
Patch number
Bank
