295
Appendices
Specifications
BR-1600CD: Digital Recording Studio
●
Tracks
Track: 16 V-Track: 256 (16 V-Tracks per each Track)
* Up to 8 tracks can be recorded simultaneously, and up to 16
tracks can be played back simultaneously.
●
Maximum Useful Capacity/Recording Time
Internal Hard Disk:
80 G bytes (recording time; 240 hours) (conversion in one track)
* The above-listed recording time is approximate. Times may be
slightly shorter depending on the number of songs and size of
imported loop phrase that were created.
* The above-listed recording time is the total for all the tracks
that are used. If each of the sixteen tracks contain an equal
amount of data, the length of the resulting song will be
approximately 1/16 of the above.
●
Signal Processing
AD Conversion: 24 bit, AF Method (Guitar/Bass)
24 bit,
Δ∑
Modulation (VOCAL)
24 bit,
Δ∑
Modulation (MULTI-TRACK)
24 bit,
Δ∑
Modulation (STEREO TRACKS)
DA Conversion: 24 bit,
Δ∑
Modulation
Internal Processing: 24 bit (digital mixer section)
Recording Data: 16 bit linear
●
Sample Rate
44.1 kHz
●
Frequency Response
20 Hz–20 kHz (+1/-3 dB)
●
Total Distortion
0.025% or less
(INPUT SENS: CENTER, 1 kHz at nominal output level)
●
Nominal Input Level (Variable)
GUITAR/BASS jack: -10 dBu
MIC 1–8 jacks (XLR): -40 dBu
INPUT 1–8 jacks: -10 dBu
●
Input Impedance
GUITAR/BASS jack: 1 M
Ω
MIC 1–8 jacks (XLR): 12.5 k
Ω
(HOT-COLD)
6.5 k
Ω
(HOT-GND, COLD-GND)
INPUT 1–8 jacks: 22 k
Ω
●
Nominal Output Level
LINE OUT jack: -10 dBu
●
Output Impedance
LINE OUT jack: 2 k
Ω
PHONES 1, 2 jack: 100
Ω
●
Recommended Load Impedance
LINE OUT jack: 20 k
Ω
or greater
PHONES 1, 2 jack: 8–50
Ω
●
Residual Noise Level
LINE OUT jack: -90 dBu or less
(INPUT SELECT: GUITAR/BASS, input terminated with 1 k
Ω
,
INPUT SENS: CENTER, IHF-A, typ.)
●
Interface
DIGITAL IN: S/PDIF 16–24 bit (coaxial type)
DIGITAL OUT: S/PDIF 16–24 bit (coaxial type)
USB connector (B type)
●
Display
130 x 36 mm (Backlit LCD)
●
Connectors
MIDI IN connector
MIDI OUT connector
USB connector
DIGITAL IN connector (coaxial type)
DIGITAL OUT connector (coaxial type)
FOOT SW jack (1/4 inch phone type)
EXP PEDAL jack (Stereo 1/4 inch phone type)
LINE OUT jacks (RCA Phono type)
INPUT 1–8 jacks (unbalanced, 1/4 inch phone type)
MIC 1–8 jacks (balanced, XLR type)
PHONES 1 jack (Stereo 1/4 inch phone type)
PHONES 2 jack (Stereo 1/4 inch phone type)
GUITAR/BASS jack (1/4 inch phone type)
