MIDI Implementation
❍
Breath type (Controller number 2)
Status
2nd byte 3rd byte
BnH 02H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
❍
Foot Type (Controller number 4)
Status
2nd byte 3rd byte
BnH 04H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
❍
Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Portamento Time: 00H - 7FH (0 - 127)
❍
Data Entry (Controller number 6, 38)
Status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
❍
Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Volume: 00H - 7FH (0 - 127)
* When the MIDI parameter “MIDI Fader SW” is set to ON, this is transmitted via the
MIDI channel set for a track when the corresponding track fader is moved, even if the
SMF is not played.
❍
Balance (Controller number 8)
Status 2nd byte 3rd byte
BnH 08H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Balance: 00H - 7FH (0 - 127)
❍
Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Panpot: 00H - 40H - 7FH (left - center - right)
❍
Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Expression: 00H - 7FH (0 - 127)
* When the MIDI parameter “MIDI Fader SW” is set to ON, this is transmitted via the
MIDI channel set for the EXP PEDAL when the EXP PEDAL is operated, even if the SMF
is not played.
❍
Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127) 0- 63 =OFF,64- 127 =ON
❍
Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127) 0- 63 =OFF,64- 127=ON
❍
Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127) 0- 63 =OFF,64- 127=ON
❍
SOFT (Controller number 67)
Status
2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127) 0- 63 =OFF,64- 127=ON
❍
Legato Foot Switch (Controller number 68)
Status
2nd byte 3rd byte
BnH 44H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127) 0- 63 =OFF,64- 127=ON
❍
HOLD 2 (Controller number 69)
Status 2nd byte 3rd byte
BnH 45H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
❍
Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv= Resonance value (relative change):00H - 40H - 7FH (-64 - 0 - +63)
❍
Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
❍
Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Attack time value (relative change): 00H - 40H - 7FH (- 64 - 0 - +63)
❍
Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Cutoff value (relative change): 00H - 40H - 7FH (- 64 - 0 - +63)
❍
Decay Time (Controller number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Decay Time value (relative change): 00H - 40H - 7FH (- 64 - 0 - +63)
❍
Vibrate Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Vibrate Rate value (relative change): 00H - 40H - 7FH (- 64 - 0 - +63)
❍
Vibrate Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Vibrate Depth value (relative change):00H - 40H - 7FH (- 64 - 0 - +63)
❍
Vibrate Delay (Controller number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Vibrate Delay value (relative change):00H - 40H - 7FH (- 64 - 0 - +63)
❍
General Purpose Controller 5 (Controller number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
