251
Saving BR-1600CD track data in WAV/AIFF format (WAV/AIFF Export)
Section 6
10.
Drag the WAV or AIFF file to the computer’s folder and
drop it in the folder.
11.
Quit the connection to the computer.
Drug the “BR-1600CD” icon to the Trash.
12.
Press the BR-1600CD’s [EXIT/NO].
The file type selection screen will be displayed once
again.
WAV or AIFF files will be automatically deleted from
the BR-1600CD’s internal hard disk.
If you press [EXIT/NO] without quitting the connection
to the computer, “Disconnect USB, OK?” appear. In this
case, pressing [ENTER/YES] returns the file format
selection screen to the display.
13.
When you have finished exporting the WAV or AIFF
file(s), press [EXIT/NO] several times to return to the
Top screen.
At this point, you can safely disconnect the USB cable
from the BR-1600CD and the computer.
If the current song contains newly recorded audio
data or newly modified settings, the message “Save
Current?” may be displayed during the export
procedure. If you want to save your song before
starting the export, press [ENTER/YES]; if this will
not be necessary, press [EXIT/NO]. Remember that
if you do not save a modified song at this time, all
newly recorded audio data, edited data, modified
mixer settings, etc. will be lost.
