Recording Equipment User Manual

213
Copying and writing waveform data
Section 4
:
Track 2, V-Track 15 T02__15.WAV or T02__15.AIF
Track 2, V-Track 16 T02__16.WAV or T02__16.AIF
:
Track 3/4, V-Track 1 T0304_01.WAV or T0304_01.AIF
Track 3/4, V-Track 2 T0304_02.WAV or T0304_02.AIF
:
Track 15/16, V-Track 15 T151615.WAV or T151615.AIF
Track 15/16, V-Track 16 T151616.WAV or T151616.AIF
12. Press [EXIT/NO] several times to return to the Top
screen.
13. Press the CD-R/RW drive’s EJECT button to eject the
disc.
14. Use the application on your computer to copy the data
from the CD-R/RW disc.
Playing SMFs using external
MIDI instruments (SMF Player)
You can use the BR-1600CD to read SMFs from CD-R/RW
discs and play these files using MIDI instruments connected
to the MIDI OUT port.
Any SMFs that satisfy the following conditions can be played
in this way.
Format:
0 or 1
File size:
250 KB maximum (Note that this will vary slightly based on
the SMF content.)
System Exclusive:
Packet sizes of 512 bytes or less
1. Connect a MIDI cable between the MIDI OUT port on
the BR-1600CD and the MIDI IN port on your external
MIDI sound module.
fig.41-25
2. Insert a CD-R/RW disc containing SMFs into the CD-R/
RW drive.
The drive’s access indicator will begin to flash. Wait until
this indicator stops flashing and turns off before
proceeding.
3. Press CD-R/RW [DATA SAVE/LOAD].
The Data CD screen will appear.
fig.41-05d
4. Press [F3] (SMF).
The function selection screen for SMFs will appear.
fig.41-27d
• If a CD-R disc that already has data written to it is
loaded, the message “Not Blank Disc” appears, and
you cannot proceed with the export. Be sure to use
only blank discs.
• If a CD-RW disc that already has data written to it is
loaded, the message “Erase Disc?” appears. Pressing
[ENTER/YES] here begins erasure of the disc. After
the disc has been erased, the export process will
continue.
• When a mono track is specified as the source for
exporting, the data is written as a mono waveform
file. When a stereo track is specified, the data is
written as a stereo waveform file.
• Tracks 9/10 –15/16 are fixed as a permanent stereo
pair, and so cannot be specified as mono tracks.
• To quit writing to the disc while writing is still in
progress, press [EXIT/NO]. When the message
“Cancel?” appears, press [ENTER/YES]; writing is
cancelled (it may take some time after you press
[EXIT/NO] for the message to appear). However, no
guarantee can be made for the utility of the content
up to the time writing is cancelled.
• It will not be possible to reuse a CD-R disc for which
writing was canceled before completion.
MIDI
IN
MIDI
OUT
