Recording Equipment User Manual

187
Section 3
Using rhythm arrangements
Selecting a rhythm arrangement
1. Make sure that PROGRAMMABLE RHYTHM
[ARRANGEMENT/PATTERN] is lighted (you’re in
Arrangement mode).
If this button’s indicator is off (meaning you’re in Pattern
mode), press PROGRAMMABLE RHYTHM
[ARRANGEMENT/PATTERN] so it is lighted.
2. Press PROGRAMMABLE RHYTHM [EDIT].
The Rhythm Arrangement Selection screen will appear.
fig.21-33d
3. Move the cursor to the rhythm arrangement number
and use the TIME/VALUE dial to select the number of
the desired rhythm arrangement.
fig.21-02d
The user rhythm arrangements and song rhythm
arrangements contained in the BR-1600CD at the time of
purchase are empty; you won’t hear anything if you select
one of them. Be sure to select a preset rhythm arrangement
here if you want to hear immediate playback.
4. Press the track buttons for Tracks 11/12 through 15/16
several times until they are lighted.
Pressing a button repeatedly allows you to cycle it
through the possible statuses, which are: Off → Flashing
→ Lighted.
Off:
No rhythm arrangement will be played.
Flashing:
Rhythm arrangement will be played only when the BR-
1600CD is recording or performing.
Lighted:
Rhythm arrangement will be always played even when
the BR-1600CD is not recording or performing.
Track 11 and 12 buttons are not lighted. They will only
be dark or flashing.
5. Raise the faders for Tracks 11/12 through 15/16 to
suitable levels.
These tracks will now be set up for playback of a rhythm
arrangement.
6. Press [PLAY] to start playback.
The drum pattern and bass pattern comprising the
rhythm arrangement will now be played.
Changing the rhythm
arrangement tempo
Two different methods can be used to set the rhythm
arrangement’s tempo—namely, setting of a fixed tempo for
the overall song and setting of tempos for individual
measures (Tempo Map (p. 198)).
The following section will describe the method for setting a
fixed tempo.
It is important to remember that whenever a fixed tempo
is set, all tempos previously set for individual measures
will be permanently overwritten with this new tempo.
1. Make sure that PROGRAMMABLE RHYTHM
[ARRANGEMENT/PATTERN] is lighted (you’re in
Arrangement mode).
If this button’s indicator is off (meaning that you’re in
Pattern mode), press PROGRAMMABLE RHYTHM
[ARRANGEMENT/PATTERN] so it is lighted.
2. Press PROGRAMMABLE RHYTHM [EDIT].
The Rhythm Arrangement Selection screen will appear.
fig.21-33d
3. Press [F1] (EDIT).
The Rhythm Arrangement Edit screen will appear.
fig.21-04d
No Loop Phrases are included in preset rhythm
arrangements, and for this reason, there will be no
playback from the Loop Phrase track (i.e., Track 11/
12). If you would also like to hear a Loop Phrase,
select either a user rhythm arrangement or a song
rhythm arrangement, and then assign a Loop Phrase
to it. (“Assembling Loop Phrases” (p. 192))
