144
Effect parameters assigned to VALUE knobs
Algorithm: VO+ACOUSTIC
Algorithm: 8CH COMP EQ
■
Vocal Tool Box
Algorithm: HARMONY SEQUENCE
Algorithm: PITCH CORRECTION
Effect Block
Parameter Abbreviation
Compressor (Mic)
On/Off M:COMP ON/OFF
Sustain M:COMP SUST
Attack M:COMP ATTACK
Level M:COMP LEVEL
Noise Suppressor (Mic)
On/Off M:NS ON/OFF
Threshold M:NS THRESH.
Release M:NS REL.
Acoustic Processor
On/Off A:AC ON/OFF
Body A:AC BODY
Mic Distance A:AC MIC.D
Level A:AC LEVEL
Compressor (Guitar)
On/Off A:COMP ON/OFF
Sustain A:COMP SUST
Attack A:COMP ATTACK
Level A:COMP LEVEL
Noise Suppressor (Guitar)
On/Off A:NS ON/OFF
Threshold A:NS THRESH.
Release A:NS REL.
Effect Block
Parameter Abbreviation
Low Cut Filter n (n = 1..8)
On/Off L.CUTn ON/OFF
Invert L.CUTn INVERT
Freq L.CUTn FREQ
Compressor n (n = 1..8)
On/Off COMPn ON/OFF
Threshold COMPn THRESH.
Knee COMPn KNEE
Ratio COMPn RATIO
Attack COMPn ATTACK
Release COMPn REL.
Level COMPn LEVEL
3Band Equalizer n (n = 1..8)
On/Off EQn ON/OFF
High Type EQn H.TYPE
High Gain EQn H.GAIN
High Freq EQn H.FREQ
High Q EQn H.Q
Mid Gain EQn M.GAIN
Mid Freq EQn M.FREQ
Mid Q EQn M.Q
Low Type EQn L.TYPE
Low Gain EQn L.GAIN
Low Freq EQn L.FREQ
Low Q EQn L.Q
Level EQn LEVEL
Effect Block
Parameter Abbreviation
Common
Input Type COMMON IN.TYPE
Balance COMMON BALANCE
Chorus Send COMMON CHO.SND
Reverb Send COMMON REV.SND
Voice n (n = 1..3)
On/Off VOICEn ON/OFF
Pre Delay VOICEn PREDLY
Pan VOICEn PAN
Human Feel VOICEn HUMAN
Effect Block
Parameter Abbreviation
Pitch Correction
Type P.CRCT TYPE
Smooth SMOOTH
