137
Section 2
Effect parameters assigned to VALUE knobs
When the effect patch selection screen is displayed, you can assign parameters you wish to control to value knobs VALUE 1
through VALUE 4.
When the effect patch selection screen is displayed, you can assign parameters you wish to control to value knobs VALUE 1
through VALUE 4.
■
Insert Effects
Algorithm: COSM OD GUITAR AMP
Effect Block
Parameter Abbreviation
COSM Overdrive/Distortion
On/Off OD/DS ON/OFF
Type OD/DS TYPE
Drive OD/DS DRIVE
Bass OD/DS BASS
Treble OD/DS TREBLE
Level OD/DS LEVEL
COSM Preamp & Speaker
Simulator
On/Off AMP ON/OFF
Type AMP TYPE
Gain AMP GAIN
Bass AMP BASS
Middle AMP MIDDLE
Treble AMP TREBLE
Presence AMP PRESNC
Level AMP LEVEL
Bright AMP BRIGHT
Gain SW AMP GAIN SW
Speaker SW SP.SIM SP SW
Speaker Type SP.SIM SP TYPE
Mic Setting SP.SIM MIC SET
Mic Level SP.SIM MIC LVL
Direct Level SP.SIM DIR.LVL
Amb Pre-Dly AMB PRE-DLY
Amb Size AMB SIZE
Amb Density AMB DENSITY
Amb HF Damp AMB HF DAMP
Amb Level AMB LEVEL
Equalizer/Wah
On/Off FILTER ON/OFF
Effect Type FILTER TYPE
4Band Equalizer
Low Gain EQ LOW
Low-Mid Freq EQ L.MID F
Low-Mid Q EQ L.MID Q
Low-Mid Gain EQ L.MID G
Hi-Mid Freq EQ H.MID F
Hi-Mid Q EQ H.MID Q
Hi-Mid Gain EQ H.MID G
High Gain EQ HIGH
Level EQ LEVEL
Wah
Type WAH TYPE
Pedal Pos. WAH PEDAL
Level WAH LEVEL
Mode A.WAH MODE
Polarity A.WAH POLARTY
Sensitivity A.WAH SENS
Frequency A.WAH FREQ
Peak A.WAH PEAK
Rate A.WAH RATE
Depth A.WAH DEPTH
Level A.WAH LEVEL
Noise Suppressor
On/Off NS ON/OFF
Threshold NS THRESH.
Release NS REL.
Foot Volume On/Off FOOT ON/OFF
FX
On/Off MOD ON/OFF
FX Select MOD SELECT
Compressor
Sustain COMP SUST
Attack COMP ATTACK
Tone COMP TONE
Level COMP LEVEL
Limiter
Threshold LIMITER THRESH.
Release LIMITER REL.
Tone LIMITER TONE
Level LIMITER LEVEL
Acoustic Guitar Simulator
Top ACOUSTC TOP
Body ACOUSTC BODY
Level ACOUSTC LEVEL
Pickup Simulator
Type PICKUP TYPE
Tone PICKUP TONE
Level PICKUP LEVEL
Tremolo
Wave Shape TREMOLO WAVE
Rate TREMOLO RATE
Depth TREMOLO DEPTH
Slow Gear
Sensitivity SLOW.G SENS
Rise Time SLOW.G TIME
Defretter
Tone DEFRET TONE
Sensitivity DEFRET SENS
Attack DEFRET ATTACK
Depth DEFRET DEPTH
Resonance DEFRET RESO
Effect Level DEFRET FX.LVL
Direct Level DEFRET DIR.LVL
Phaser
Type PHASER TYPE
Rate PHASER RATE
Depth PHASER DEPTH
Manual PHASER MANUAL
Resonance PHASER RESO
Step PHASER STEP
Step Rate PHASER S.RATE
Effect Level PHASER FX.LVL
Direct Level PHASER DIR.LVL
Flanger
Rate FLANGER RATE
Depth FLANGER DEPTH
Manual FLANGER MANUAL
Resonance FLANGER RESO
Separation FLANGER SEP
Effect Level FLANGER FX.LVL
Direct Level FLANGER DIR.LVL
Pitch Shifter
Voice P.SHIFT VOICE
Mode 1 P.SHIFT MODE1
Pitch 1 P.SHIFT PITCH1
Fine 1 P.SHIFT FINE1
Pre Delay 1 P.SHIFT PREDL1
Feedback 1 P.SHIFT FBK1
Level 1 P.SHIFT LEVEL1
Mode 2 P.SHIFT MODE2
Pitch 2 P.SHIFT PITCH2
Fine 2 P.SHIFT FINE2
Pre Delay 2 P.SHIFT PREDL2
Level 2 P.SHIFT LEVEL2
Direct Level P.SHIFT DIR.LVL
2x2 Chorus
Xover Freq 2CHORUS XOVER
Low Rate 2CHORUS L.RATE
Low Depth 2CHORUS L.DEPTH
Low Pre-Dly 2CHORUS L.PREDLY
Low Level 2CHORUS L.LEVEL
High Rate 2CHORUS H.RATE
High Depth 2CHORUS H.DEPTH
High Pre-Dly 2CHORUS H.PREDLY
High Level 2CHORUS H.LEVEL
Effect Block
Parameter Abbreviation
