128
Speaker Modeling parameter functions
Bass Cut Filter
This filter cuts out vocal pop and other unwanted low-band
noise.
On/Off OFF, ON
This setting turns the Bass Cut Filter on or off.
Cut Off Freq THRU, 20 –2000 Hz
This parameter sets the frequency below which vocal pop and other
undesirable lower-range noises will be filtered out.
Low Freq Trimmer
This trimmer is used to process low frequencies.
On/Off OFF, ON
Switches the low frequency trimmer on or off.
Gain -12–+12 dB
Adjusts the gain (i.e., the amount of boost or cut) for the low
frequency trimmer.
Frequency 20–2000 Hz
Specifies the center frequency for the low frequency trimmer.
High Freq Trimmer
This trimmer is used to process high frequencies.
On/Off OFF, ON
Switches the high frequency trimmer on or off.
Gain -12–+12 dB
Adjusts the gain (i.e., the amount of boost or cut) for the high
frequency trimmer.
Frequency 1.0–20.0 kHz
Specifies the center frequency for the high frequency trimmer.
Limiter
A limiter reduces loud input levels to prevent distortion.
On/Off OFF, ON
Switches the limiter on or off.
Threshold -60–0 dB
Adjust this parameter to match the input signal. Limiting will be
applied to input levels in excess of this level.
Release 0–100
This adjusts the time it takes for limiting to be removed once the
signal level drops below the threshold.
Level -60–+24 dB
This parameter adjusts the overall volume.
