Other Operations
85
GB
• If an error message appears, follow the message,
then select [YES].
An error message appears when:
– the headphones are connected to the unit or
surround amplifier*.
– the calibration mic is not connected.
– front speakers are not correctly connected.
– surround speakers are not correctly
connected.
– front and surround speakers are not correctly
connected.
* DAV-HDX275/DAV-HDX475 only.
10 Press C/c to select [YES] or [NO], then
press .
x The measurement is OK.
Disconnect the calibration mic, then select
[YES]. The result is implemented.
x The measurement is not OK.
Follow the message, then select [YES] to
retry.
Note
• While the Auto Calibration function works:
– do not turn off the power.
– do not press any button.
– do not change the volume.
– do not change the function.
– do not change the disc.
– do not insert or eject a disc.
– do not connect the headphones to the unit or
surround amplifier*.
– do not disconnect the calibration mic.
* DAV-HDX275/DAV-HDX475 only.
• The measurement for [SUBWOOFER] is always
[YES] since the system does not perform subwoofer
calibration.
Ti
p
• You can check the distance between the listening
position and each speaker. See page 67.
Controlling the TV with
the Supplied Remote
You can control the TV (Sony only) by using
following buttons. Use these buttons (other than
TV [/1, THEATER/THEATRE*, TV INPUT,
and TV VOL +/–) while pressing the TV button.
* The button name differs depending on the area.
Note
• Depending on the TV, you may not be able to control
your TV or to use some of the buttons.
• Depending on the area, the name of the button may
differ.
* Use these buttons while pressing the TV button.
By pressing You can
TV [/1 Turn the TV on/off.
THEATER
(
THEATRE)
Enjoy optimal image suited for
movies.
TV INPUT Switch the TV’s input source
between the TV and other input
sources.
TV VOL +/– Adjust the TV volume.
TV CH +/–*
(PROG +/–*)
Select the TV channel.
Number
buttons*,
-*
ENTER*
Select the TV channel.
TOOLS* Displays the operation menu for
the current display.
RETURN* Return to the previous channel or
layer on the menu of the TV.
MENU* Display the menu of the TV.
MUTING* Turn off the TV sound
temporarily.
C/X/x/c*, * Select the item on the menu.
