44 Chapter 5: The Playback tab
System mute button
Use the System Mute button to mute the playback. When you
press the button again to unmute, there is a short ramp-up time
before full volume is restored. The ramp-up time cannot be
adjusted.
Figure 5.11 - System Mute button
Record button and elapsed time field
Processed audio can be recorded and saved to a (.wav) file for
future playback. When recording, the current recording duration is
displayed in the elapsed time field located below the record toggle
button. To stop recording, click on the toggle a second time. For
more information, see Chapter 7: Record audio output, on page 53.
Figure 5.12 - Record button and elapsed time field
Tip: If you have enabled Direct keys, you can use the direct key
shortcut to mute the sound: the M key. You can enable Direct
keys in the General tab of the Application Preferences dialog
box. To mute the signal, press pause in Media Player.
