User guide

Bose
®
Modeler
®
Plus 6.5 Software User Guide Supplement
Chapter 2: Modeler Plus Software Tutorial 17
13. Click on the Add File button, or Add Track button in the Bose
Media Player to load an audio track.
Figure 2.7 - Add File and Add Track buttons
Select a track or audio file and press the Play button to begin
playback. The processed audio for the listener begins playing
through the Auditioner
®
Playback System III once the system
mute button is toggled to the unmute state.
14. Select the Playback tab in the Data window:
Figure 2.8 - Playback tab
The Playback tab displays the playback queue and includes
controls for playback. Use the up and down buttons to scroll
through the listeners.
15. Verify that the levels are below 100 dB for comfortable playback.
16. If OK, unmute.
Add File
: Allows you to load a (.wav) audio file from
your hard drive or an external drive.
Add Track: Allows you to load a track from an audio CD.
