User guide

Bose
®
Modeler
®
Software Plus 6.5 User Guide Supplement
16 Chapter 2: Modeler Plus Software Tutorial
10. It is always a good idea to mute playback before loading
listeners. Once loaded, we will inspect the room meter to make
sure that the playback is at a reasonable level.
Press the Mute playback button, or use the direct key M to mute
playback volume. Press again to unmute.
Figure 2.5 - Mute playback button shown in mute state
11. Click in the selection box in column 1 of the Playlist window to
select a location for playback. An “X” is drawn in the selection
box. This places the listener in the playback queue. The green
loudspeaker icon indicates which listener is currently playing.
Figure 2.6 - Place an “X” to load listeners
12. If the Bose Media Player is already open, bring it to the front
by clicking the Windows
®
Taskbar.
