en Table of contents no i t c u r t s n I ] ne [ 8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 ( Important safety information . . . . . . . . . . . . . . . 5 ] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 7 Environmental protection . . . . . . . . . . . . . . . . . . 7 Energy-saving advice . . . . . . . . . . . . . . . . . . . . . . . . . .
en Intended use 8Intended use Read these instructions carefully. Please keep the instruction and installation manual, as well as the appliance certificate, in a safe place for later use or for subsequent owners. Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will lose your right to any type of compensation.
Important safety information (Important safety information : Warning – Risk of fire! no i t amro f n i y t e f as t na t ropmI Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar. Risk of fire! ■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
en Causes of damage ]Causes of damage Caution! ■ Rough pan bases may scratch the hob. ■ Avoid leaving empty pots and pans on the hotplate. Doing so may cause damage. ■ Do not place hot pans on the control panel, the indicator area, or the hob frame. Doing so may cause damage. ■ Hard or pointed objects dropped on the hob may damage it. ■ Aluminium foil and plastic containers will melt if placed on the hotplate while it is hot. The use of laminated sheeting is not recommended on the hob.
Environmental protection 7Environmental protection In this section, you can find information about saving energy and disposing of the appliance. no i t ce t orp l a t nemnor i vnE Energy-saving advice ■ ■ ■ ■ ■ ■ Always use the correct lid for each pan. Cooking without a lid uses a lot more energy. Use a glass lid to provide visibility and avoid having to lift the lid. Use pans with flat bases. Bases that are not flat use a lot more energy.
en Induction cooking Some induction cookware does not have a fully ferromagnetic base: ■ ■ If the base of the cookware is only partially ferromagnetic, only the area that is ferromagnetic will heat up. This may mean that heat will not be distributed evenly. The non-ferromagnetic area may not heat up to a sufficient temperature for cooking. The ferromagnetic area will also be reduced if the material from which the base of the cookware is made contains aluminium, for example.
Getting to know your appliance en *Getting to know your appliance You can find information on the dimensions and power of the hotplates in~ Page 2 ecna i l p a ruoy wonk o t gn i t eG The control panel Indicators Controls # ã Main switch 0 1Ê2Ê...
en Getting to know your appliance The hotplates Hotplates Simple hotplate Û Þ á Use cookware that is a suitable size Middle simple hotplate Use cookware that is a suitable size Flexible cooking zone See section ~ "Flex Zone" Only use cookware that is suitable for induction cooking; see section ~ "Induction cooking" Residual heat indicator The hob has a residual heat indicator for each hotplate. This indicates that a hotplate is still hot.
Operating the appliance 1Operating the appliance This chapter explains how to set a hotplate. The table shows heat settings and cooking times for various meals. en Changing the heat setting Select the hotplate and then set the required heat setting in the control panel. ecna i l p a eh t gn i t arepO Switching the hob on and off The main switch is used to switch the hob on and off. To switch on: Touch the # symbol. An audible signal sounds.
en Operating the appliance Cooking table The table shows which heat setting is suitable for each type of food. The cooking time may vary depending on the type, weight, thickness and quality of the food. Heat setting Cooking time (mins) Melting Chocolate coating Butter, honey, gelatine 1 - 1.5 1-2 - Heating and keeping warm Stew, e.g. lentil stew Milk* Heating sausages in water* 1.5 - 2 1.5 - 2.
Operating the appliance Roasting/frying with little oil* Escalope, plain or breaded Escalope, frozen Chop, plain or breaded** Steak (3 cm thick) Poultry breast (2 cm thick)** Poultry breast, frozen** Rissoles (3 cm thick)** Hamburgers (2 cm thick)** Fish and fish fillet, plain Fish and fish fillet, breaded Fish, breaded and frozen, e.g.
en Flex Zone |Flex Zone You can use the hob as a single hotplate or as two independent hotplates, as required. It consists of four inductors that work independently of each other. If using the flexible cooking zone, only the area that is covered by cookware is activated.
Move function uMove function This function activates the entire flexible cooking zone, which is divided into three cooking areas and which has preset heat settings. Only use one item of cookware. The size of the cooking area depends on the cookware used and whether it is positioned correctly. no i t cnu f evoM Cooking areas en Activation 1. Select one of the two hotplates in the flexible cooking zone. 2. Touch the ç symbol. The indicator beside the ç symbol lights up.
en Time-setting options OTime-setting options Your hob has three timer functions: sno i t po gn i t es -emi T ■ ■ ■ Programming the cooking time Kitchen timer Stopwatch function Programming the cooking time The hotplate automatically switches off after the time that is set has elapsed. Setting procedure: 1. Select the hotplate and the required heat setting. 2. Touch the y symbol. The ‹‹ symbol and theV indicator light up in the timer display. y lights up in the display for the hotplate.
PowerBoost function When the time has elapsed An audible signal sounds once the time has elapsed. ‹‹ and the V symbol flash in the timer display. The indicators go out after touching the t symbol. Stopwatch function The stopwatch function displays the time that has elapsed since activation. This functions independently from the hotplates and from other settings. This function does not automatically switch off a hotplate.
en ShortBoost function xShortBoost function The PowerBoost function enables you to heat cookware faster than when using heat setting Š. no i t cnu f t so Bt rohS After deactivating the function, select the appropriate heat setting for your food. This function can always be activated for a hotplate, provided the other hotplate in the same group is not in use (see illustration). zKeep warm function This function is suitable for melting chocolate or butter and for keeping food warm.
Cooking assist functions ÜCooking assist functions The cooking assistance functions make cooking easy and always give you excellent results. The recommended temperature settings are suitable for any type of cooking. They enable you to cook without using excessive heat and promise the perfect cooking and frying results. Sensors measure the heat of the saucepan or frying pan throughout the cooking process. This ensures that the power is continuously controlled and that the right temperature is maintained.
en Cooking assist functions Suitable cookware Functions and heat settings Select the hotplate the diameter of which most closely matches that of the base of the cookware and place the cookware in the centre of this hotplate. The cooking functions are not suitable for frying food in a pan like you can with the frying sensor. There are frying pans that are perfect for using with the frying sensor. These can be purchased from specialist retailers or through our technical after-sales service.
Cooking assist functions en Temperature settings Temperature setting 1 Very low 2 Low 3 Medium - low 4 Medium - high 5 High Suitable for Preparing and preserving sauces, sweating vegetables and frying food in extra virgin olive oil, butter or margarine. Frying food using extra virgin olive oil, butter or margarine, e.g. omelettes. Frying fish and Thick food, e.g. meatballs and sausages. Frying steaks, medium or well-done, frozen, breaded and fine foods, e.g. escalope, fresh ragout and vegetables.
en Cooking assist functions Temperature ranges and settings Cooking functions Heating, keeping warm Poaching Cooking Cooking in a pressure cooker Frying with a large amount of oil in the saucepan Temperature setting 1/70 ºC 2/90 ºC 3/100 ºC 4/120 ºC 5/170 ºC Tips for cooking with the cooking functions ■ ■ ■ ■ ■ Heating/keep-warm function: Frozen products in portions, e.g. spinach. Place the frozen product in the cookware. Add the quantity of water specified by the manufacturer.
Cooking assist functions Connecting the wireless temperature sensor to the control panel You will need to connect the wireless temperature sensor to the control panel before using the cooking functions for the first time. To connect the wireless temperature sensor to the control panel, follow the instructions below: 1. Select the ™‚… menu; see the section on ~ "Basic settings" The hotplate indicator will light up. 2. Select the hotplate and its indicator will light up. A signal will sound.
en Cooking assist functions Recommended dishes The following table shows a selection of dishes and is arranged by food type. The temperature and the cooking time depend on the amount, the condition and the quality of the food.
Cooking assist functions Egg-based dishes Frying with a small amount of oil function Crêpes* Omelette* Fried eggs Scrambled eggs Kaiserschmarrn (shredded pancake) French toast Cooking function Hard-boiled eggs** * Total time for each portion. Fry one after the other. ** Add the food straight away.
en Cooking assist functions Potatoes Cooking assistance Temperature Total cooking time functions setting from signal (mins) Frying with a small amount of oil function Fried potatoes (made from potatoes boiled in their skins) Fried potatoes (made from raw potatoes) Potato rösti* Swiss rösti Glazed potatoes Frying sensor Frying sensor Frying sensor Frying sensor Frying sensor 5 4 5 1 3 6 - 12 15 - 25 2.5 - 3.
Cooking assist functions Sauces Frying with a small amount of oil function Tomato sauce with vegetables Béchamel sauce Cheese sauce, e.g. Gorgonzola sauce Reducing sauces, e.g. tomato sauce, bolognese sauce Sweet sauces, e.g.
en Cooking assist functions Further cooking assistance Temperature Total cooking time functions setting from signal (mins) Frying with a small amount of oil function Camembert/cheese Precooked dry products that require water to be added, e.g. pasta Croutons Almonds/nuts/pine nuts Frying sensor Frying sensor Frying sensor Frying sensor 3 1 3 4 7 - 10 5 - 10 6 - 10 3 - 15 Heating/keep-warm function Food in jars and tins, e.g.
Cooking assist functions Using the wireless temperature sensor Attach the temperature sensor to the silicone patch and align it correctly. en 2. Remove the upper section of the casing. Take the old batteries out. Put the new batteries in. Make sure that the polarity is correct. Notes ■ Make sure that the silicone patch is completely dry before attaching the temperature sensor. ■ Position the cookware in such a way that the temperature sensor is pointing towards the outer side of the hob.
en Childproof lock Declaration of Conformity Robert Bosch Hausgeräte GmbH hereby declares that the appliance with wireless temperature sensor function meets the basic requirements and other relevant provisions of the Directive 1999/5/EG. A detailed R&TTE Declaration of Conformity can be found online at www.bosch-home.com on the product page for your appliance under "Additional documents". AChildproof lock You can use the childproof lock to prevent children from switching on the hob.
Wipe protection kWipe protection If you wipe over the control panel while the hob is switched on, settings may be altered. To avoid doing this, you can use the hob's "Lock control panel for cleaning" function. n o i t c e t o r p e p iW To switch on: Touch the > symbol. An audible signal sounds. The control panel is locked for 35 seconds. You can now wipe over the surface of the control panel without altering any settings. To deactivate: The control panel will be unlocked once 35 seconds have elapsed.
en Basic settings QBasic settings The appliance has various basic settings. You can adapt these to suit your cooking habits. sgn i t es c i saB Display Function ™‚ Automatic childproof lock ‹ ‚ ƒ ™ƒ Audible signals ‹ ‚ ƒ „ ™„ Switched off.* Switched on. Set according to height above sea level ‚-ƒ „ …-Š ™† Confirmation and fault signals are switched off. Only the fault signal is switched on. Only the confirmation signal is switched on. All signal tones are switched on.
Basic settings Display Function ™‚„ Configuring activation of the flexible cooking zone ‹ ‚ ™‚… As two independent hotplates.* As a single hotplate. Connecting the wireless temperature sensor to the hob ‹ ‚ ƒ ™‹ en Connected correctly Not connected correctly: Transmission error. Not connected correctly: Temperature sensor fault. Restoring the factory settings ‹ ‚ Individual settings.* Restore factory settings. * Factory settings 5.
en Energy consumption indicator [Energy consumption indicator This function indicates the total amount of energy consumed by this hob the last time it was used for cooking. Once switched off, the energy consumption in kWh is displayed for 10 seconds. The picture shows an example with an energy consumption of ‚.‹‰ kWh. ro t ac i dn i no i t pmusnoc ygrenE tCookware check This function can be used to check the speed and quality of the cooking process depending on the cookware.
Cleaning DCleaning Suitable maintenance and cleaning products can be purchased from the after-sales service or in our e-Shop. gn i nae l C Hob Cleaning Always clean the hob after cooking. This will prevent food deposits from becoming burned on. Only clean the hob after the residual heat indicator has gone out. Clean the hob with a damp dish cloth and dry it with a cloth or towel to prevent limescale build-up. Only use cleaning agents that are suitable for this type of hob.
en Frequently Asked Questions (FAQ) {Frequently Asked Questions (FAQ) )QAF( sno i t seuQ deksA y l t neuqerF Using the appliance Why can't I switch on the hob and why is the childproof lock symbol lit? The childproof lock is activated. You can find information on this function in the section on ~ "Childproof lock" Why are the displays flashing and why can I hear an audible signal? Remove any liquid or food remains from the control panel. Remove any objects from the control panel.
Trouble shooting en Cleaning How do I clean the hob? Using a special glass-ceramic cleaning agent produces the best results. We advise against using harsh or abrasive cleaning agents, dishwater detergent (concentrated) or scouring pads. You can find more information on cleaning and caring for your hob in the section on ~ "Cleaning" 3Trouble shooting Usually, faults are small matters that are easy to eliminate. Please read the information in the table before calling the after-sales service.
en Customer service Display The indicator on the temperature sensor flashes twice. The indicator on the temperature sensor flashes three times. “Š‹‹‹ “Š‹‚‹ —…‹‹ š“ Possible cause The battery in the temperature sensor has almost run out. You may be interrupted the next time you cook by the battery running out. The temperature sensor is disconnected. Remedial action Change the 3V CR2032 battery.
Test dishes en ETest dishes This table has been produced for test institutes to facilitate the testing of our appliances. The data in the table refers to our Schulte-Ufer cookware accessories (4 piece cookware set for the HEZ 390042 induction hob) with the following measurements: s e h s i d t s eT ■ ■ ■ ■ Saucepan Ø 16 cm, 1.2 l for hotplates of Ø 14.5 cm Pot Ø 16 cm, 1.7 l for hotplates of Ø 14.5 cm Pot Ø 22 cm, 4.
en Test dishes Test dishes Preheating Heat set- Cooking time Cookware Lid ting (min:sec) Cooking rice pudding Rice pudding, cooked with the lid on Temperature of the milk: 7 ºC Heat the milk until it starts to rise up. Set the recommended heat setting and add rice, sugar and salt to the milk. The cooking time, including preheating, is approx. 45 minutes. Ingredients: 190 g short-grain rice, 90 g sugar, 750 ml milk (3.
